Spinlocks

 Spinlocks

This talk presents an overview of spinlocks. We cover cache coherency models and discover ways we can make spinlocks more efficient with respect to modern hardware. We discuss some potentially undesirable properties of unfairness in spinlocks and look at implementations of fair spinlocks including ticket locks, array locks, MCS locks, and CLH locks.

Presented to the Operating Systems class at Johns Hopkins University as a guest lecture with Samy Al Bahra.

083a38739359a3cb689c5be4cd7a1985?s=128

Devon H. O'Dell

April 08, 2011
Tweet

Transcript

  1. Spinlocks Spinlocks Samy Al Bahra Devon H. O’Dell Message Systems,

    Inc. April 8, 2011
  2. Spinlocks Introduction Mutexes A mutex is an object which implements

    acquire and relinquish operations such that the execution following an acquire operation and up to the relinquish operation is executed in a mutually exclusive manner relative to the object implementing a mutex.
  3. Spinlocks Introduction Locks Locks are an implementation of a mutex.

    Sleep lock Any mutex type which deactivates processes that attempt to acquire a mutex that has already been acquired by another process until a relinquish operation on the mutex activates one or more of them. Spinlock Any mutex type which forces callers of an acquire operation to spend an unbounded number of processor cycles re-evaluating the availability of the mutex until it has been acquired. The process that invokes acquire is never deactivated before the completion of the acquire operation. Spinlocks are preferred to sleep mutexes when the waiting time for a resource is less than the time for the scheduling overhead of process activation/deactivation or when scheduling simply is not possible.
  4. Spinlocks Non-Arbitrating Spinlocks Naive void lock(uint32_t *mutex) { while (ck_pr_fas_32(mutex,

    true) != false) ck_pr_stall(); return; } void unlock(uint32_t *mutex) { *mutex = false; return; }
  5. Spinlocks Non-Arbitrating Spinlocks Naive 3e+07 4e+07 5e+07 6e+07 7e+07 8e+07

    9e+07 1e+08 1.1e+08 1.2e+08 1.3e+08 2 3 4 5 6 7 8 9 10 11 12 Total Acquisitions (in 10 seconds) Number of Cores Naive
  6. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  7. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  8. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  9. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  10. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  11. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  12. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  13. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  14. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  15. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  16. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  17. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  18. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  19. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  20. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  21. Spinlocks Non-Arbitrating Spinlocks Cache Coherency

  22. Spinlocks Non-Arbitrating Spinlocks TATAS void lock(uint32_t *mutex) { while (ck_pr_fas_32(mutex,

    true) != false) { while (ck_pr_load_32(mutex) == true) ck_pr_stall(); } return; } void unlock(uint32_t *mutex) { *mutex = false; return; }
  23. Spinlocks Non-Arbitrating Spinlocks TATAS 2e+07 4e+07 6e+07 8e+07 1e+08 1.2e+08

    1.4e+08 1.6e+08 2 3 4 5 6 7 8 9 10 11 12 Total Acquisitions (in 10 seconds) Number of Cores Naive TATAS
  24. Spinlocks Non-Arbitrating Spinlocks Exponential Backoff void lock(uint32_t *mutex) { ck_backoff_t

    backoff = CK_BACKOFF_INITIALIZER; while (ck_pr_fas_32(mutex, true) != false) ck_backoff_eb(&backoff); return; } void unlock(uint32_t *mutex) { *mutex = false; return; }
  25. Spinlocks Non-Arbitrating Spinlocks Exponential Backoff 0 2e+08 4e+08 6e+08 8e+08

    1e+09 1.2e+09 1.4e+09 2 3 4 5 6 7 8 9 10 11 12 Total Acquisitions (in 10 seconds) Number of Cores Naive TATAS EB
  26. Spinlocks Non-Arbitrating Spinlocks Fairness 0 5e+06 1e+07 1.5e+07 2e+07 2.5e+07

    3e+07 3.5e+07 4e+07 4.5e+07 Total Acquisitions (1o seconds) Processor
  27. Spinlocks Non-Arbitrating Spinlocks Fairness Non-arbitrating spinlocks do not provide fairness

    (or starvation-freedom) guarantees.
  28. Spinlocks Non-Arbitrating Spinlocks Ticket 0 1 0 2 2 1

    3 2 3 Now Serving: 0 Now Serving: 0 Now Serving: 1 Now Serving: 2 Now Serving: 3 LOCK LOCK, LOCK UNLOCK UNLOCK UNLOCK UNLOCK, LOCK 4 Now Serving: 4 UNLOCK
  29. Spinlocks Non-Arbitrating Spinlocks Anderson U L L L U L

    L L U L L L L U L L L U L L P P P P P L L U L P L L U L P LOCK LOCK UNLOCK LOCK UNLOCK LOCK L L L U P U L L L P UNLOCK UNLOCK
  30. Spinlocks Non-Arbitrating Spinlocks MCS L L T0 R L T0

    R T1 S L T0 R T1 S FAS L T0 N T1 S R = Running S = Spinning N = Notify L T1 R T0 LOCK T1 LOCK T0 UNLOCK
  31. Spinlocks Non-Arbitrating Spinlocks MCS L T1 R T2 S L

    T1 S T2 S L T1 N T2 S L T2 R T2 LOCK T1 UNLOCK
  32. Spinlocks Non-Arbitrating Spinlocks CLH Stub Stub T0 Stub T0 T1

    T1 LOCK LOCK UNLOCK Stub T0 T1 T0 T1 UNLOCK R R R S S
  33. Spinlocks Non-Arbitrating Spinlocks Fast path latency Fast path latency See

    http://concurrencykit.org/doc/appendixZ.html
  34. Spinlocks Non-Arbitrating Spinlocks Limitations Mutexes in general are not composable.

    Subtle ordering issues can lead to hard-to-detect deadlock conditions. Blocking synchronization is sensitive to preemption.
  35. Spinlocks Discussion Questions?
