  1. Building a Device Lab Destiny Montague and Lara Hogan co-LAB-orators

    at Etsy Slides and links: larahogan.me/devicelab/
  2. Reminder: have your visitor’s  device data ready!

  3. What is Etsy? (and who are we?)

  4. Engineering Teams at Etsy • Feature Teams • Listing page

    • Seller tools • Checkout
  5. Engineering Teams at Etsy • Feature Teams • Listing page

    • Seller tools • Checkout • Infrastructure Teams • Performance • Dev tools • Security Destiny
  6. Why’d we build a device lab?

  7. traffic to Etsy from mobile web+apps: > 50%

  8. How many times have we built a device lab?

  9. v1: Gray Cabinet v2: Bookshelves v3: Leaning Tower Our device

    lab’s history
  10. Our device lab by the numbers • 36 devices •

    8 operating systems • 45 average users/month • 4 median checkouts/device • 8 devices retired this year,
 12 new purchased v3: Leaning Tower
  11. a note about privilege

  12. what works for us  may not work for you

  13. What we’ll cover today 1. Choosing Devices (10 min) 2.

    Power (20 min) 3. Device Setup (10 min) 4. Setting Up Testing (5 min) 5. Networking, RFID Readers (15 min) 6. User Experience & Organization (15 min)
  14. Choosing Devices

  15. find your visitors’ devices

  16. None
  17. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  18. Get the most bang for your buck

  19. focus on the 20% of devices that produce
 80%

    of your traffic
  20. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  21. cover your visitors’ screen sizes and operating systems

  22. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  23. buggiest: Kindle, older Android

  24. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  25. Does usage differ if you segment by audience region

    or target market?
  26. combination of  touch and cursor

  27. retina/DPI

  28. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  29. Device OS Version % Total Sessions Size Apple iPhone 7.1

    40% handset Apple iPad 7.1 7.9% small/large tablet Apple iPhone 7.0.6 4.9% handset LG Nexus 5 4.4.2 4.5% handset Google Nexus 4 4.4.2 4% handset Apple iPhone 7.0.4 3.2% handset Apple iPhone 7.1.1 3.2% handset Google Nexus 4 4.3.1 2.5% handset Google Nexus 7 4.4.2 2.1% small tablet Apple iPhone 6.1.3 1.5% handset
  30. purchasing devices

  31. used devices better- represent battery life

  32. wifi-capable vs. data plan

  33. eBay, Amazon,  local cell phone dealers

  34. our devices

  35. In our lab: • 12 Android phones (a range of

    operating system versions and major manufacturers) • 3 Android tablets (a range of screen resolutions) • 1 Blackberry phone • 1 Firefox phone (developer preview) • 5 iPads (including 1 mini, different generations)
  36. In our lab (cont’): • 5 iPhones/iPods • 1 Kindle

    Fires (range of screen resolutions) • 1 Windows Phone, 1 Windows Surface, 1 Dell laptop • 1 Google Glass, 1 Chromebook Pixel • 1 Raspberry Pi, and some Kubis
  37. More reading • Strategies for choosing test devices:
 http://stephanierieger.com/strategies-for-choosing-test-

    devices/ • How to build a device lab, with a thorough first section on choosing and acquiring devices:
 http://dmolsen.com/2012/06/26/how-to-build-a- device-lab-part-1/
  38. questions?

  39. Power

  40. None
  41. electricity 101

  42. https://www.flickr.com/photos/marktee/9223003535 electricity = water

  43. https://www.flickr.com/photos/marktee/9223003535 usb/power cables = garden hose

  44. amps vs. volts

  45. amperage

  46. voltage

  47. volts * amps = watts!

  48. None
  49. power considerations

  50. how much power does each device draw,
 according to

    the manufacturer's specs?
  51. how much power can the
 surge protector  support?

  52. how much power can each usb hub support?

  53. None
  54. build to support  your most  power-hungry devices

  55. power problems

  56. power problems won’t accept a charge cycle on/off forever won’t

    turn on blinking battery can’t hold a charge someone stole the battery
  57. http://www.microsoft.com/surface/en-us/support/warranty-service-and-recovery/

  58. troubleshooting

  59. start simple

  60. "When you see hoof prints,  look for horses,

    not zebras"
  61. isolate the problem

  62. DEVICE HARDWARE SOFTWARE

  63. DEVICE HARDWARE cables charging port peripherals SOFTWARE battery display

  64. DEVICE HARDWARE SOFTWARE apps operating system your base image cables

    charging port peripherals battery display
  65. why?

  66. •devices drew too much power ! •devices weren’t getting enough

    power ! •bad USB cables / peripherals ! •bad software ! •bad device
  67. iterating on power

  68. v1 - power strips

  69. v2 - stupid USB hubs

  70. v3 - better USB hubs

  71. Cambrionix hub

  72. Cambrionix hub • 32 ports • smart power delegation •

    fault indicator • disables problem devices
  73. v4 - better cabling/monitoring

  74. energy consumption

  75. None
  76. modlet timer

  77. None
  78. pro power tips

  79. http://iheartorganizing.blogspot.com/2012/03/you-asked-organizing-cords.html

  80. have spares/duplicates as back-ups

  81. have extra cables handy for people to steal

  82. questions?

  83. Device Setup

  84. configuration

  85. factory (re)format

  86. disable  auto-updates

  87. create an  app store account

  88. install apps

  89. restrict devices from syncing to computers

  90. set browser default homepage

  91. make use of wallpaper

  92. set up a passcode

  93. have a way to identify devices

  94. have a backup image

  95. enroll devices in a  mobile device management console (MDM)

  96. choosing your MDM

  97. scalability

  98. app management

  99. admin console

  100. security

  101. http://www.enterpriseios.com/wiki/Comparison_MDM_Providers MDM providers

  102. questions?

  103. Testing

  104. None
  105. None
  106. 0. set up an Adobe account with the device lab

     email address ! (save this password somewhere;  you’re gonna need it later.)
  107. 1. install the Adobe Edge Inspect app via Creative Cloud

    desktop app ! (yeah, you need them both. and it has to be running for everything else to work.)
  108. 2. install the  browser  extension ! (it’ll remind

    you to turn on the  application if you haven’t yet.)
  109. 3. install the app on  iOS, Android and

    Kindle devices ! (right, it’s not on every operating system yet, and this is a great case for getting an MDM.)
  110. 4. enter the pin for  each device in the

    browser extension ! (you’ll have to upgrade to test on  multiple devices at once.) http://www.adobe.com/inspire/2012/12/web-designs-edge-inspect.html
  111. if you upgrade your account, you’ll want to reuse it

    on every laptop used for testing...
  112. which is why it’s great to keep one laptop in

    the lab for this express purpose.
  113. None
  114. save all the  screenshots at once! http://www.adobe.com/inspire/2012/12/web-designs-edge-inspect.html

  115. development machines & staging environments

  116. ensure it’s easy to  test development on your devices

  117. ensure it’s easy to  test all environments on

    your devices
  118. None
  119. questions?

  120. Networking

  121. get connected

  122. use wifi

  123. bypass activation

  124. http://www.droidxforums.com/forum/droid-x-faqs/506-bypass-android-activation-screen-motorola-droid-x.html B A

  125. designate your  own network

  126. private SSID

  127. Guest Network Internal Network Device Lab Network Access - basic

    web - no internal sites - VPN is blocked ! - basic web - access to internal sites - some sites require VPN access to prod network - basic web - only pre-production/ testing & VM stuff that is essential for testing our internal wifi networks
  128. networking problems

  129. decrease in  wireless range

  130. decrease in data throughput

  131. intermittent or dropped wifi connection

  132. difficulty pairing  with bluetooth

  133. signal-to-noise ratio

  134. signal-to-noise ratio

  135. None
  136. RFID <3

  137. None
  138. what is RFID?

  139. “Wireless non-contact use of radio-frequency electromagnetic fields to transfer data.”

  140. None
  141. high or low frequency

  142. employee badges

  143. usefulness

  144. links to employee

  145. saves time

  146. can provide stats and trends

  147. less expensive

  148. components
