1. 天然氣節能設備說明
2. 天然氣節能設備說明 1.設備為不锈鋼外殼及耐高溫泡棉、合成氧化物組成: 泡棉層填充並固設於該容置室內，該泡棉為低密度泡棉含有天然礦石所合成 之合成氧化物粉層，且於內部具有複數孔隙通道。氣態燃料可經由該孔隙通道而 流過節能設備，並直接與該泡棉層內的合成氧化物交互作用，從而促進燃燒效率， 有效達到節能減碳之效果。 2.節能設備功能類似汽車的觸媒轉換器 燃料及空氣通過節能設備時會和CH4及H2O當中的H作用產生氫氧自由基 OH，氫氧自由基OH是強氧化物，會強烈氧化有機物質，大幅提燃燒效率。 反應啟動後，會使燃燒狀態比未安裝設備前來得更為劇烈，使其火力增加， 而增加的火力即是我們可以節省的部分，通常以降低瓦斯量的輸入來做調整。 甲烷的燃燒是一個多步反應。下面是燃燒的反應式： CH 4 + 2O 2 → CO 2 + 2H 2 O 節能設備不具備流體加速或減速功能，安裝位置在燃燒設備的外部，並不會 改變原本操作鍋爐或燃燒的方式。
3. C 2 H 2 乙炔火焰測試 在乙炔與氧氣管道上(純氧燃燒)分別安裝節能設備 乙炔設備 氧氣設備
4. 未安裝與安裝火焰情況比較 條件設定：同規格火焰噴嘴、同樣氣體壓力（C 2 H 2 ；O 2 ） 火力更強 先提高燃燒狀態,再來節省 未安裝 有安裝
5. 熱媒鍋爐︰ 鍋爐規格：臥式，發熱量150萬Kcal 鍋爐應用：加熱化學槽 燃燒機 ：臺製、無熱回收、鼓風機馬力5HP 瓦斯設備 三通設計 空氣設備 比原管道截面 積放大8-10倍
6. 瓦斯度數 每分鐘用量 時間 回油溫度 出油溫度 相差 每一度天然氣所升高溫度 610.40 0 136.8 155.4 611.10 0.70 1 137.2 154 17.2 24.571 611.80 0.70 2 137.5 154.2 17 24.286 612.48 0.68 3 137.6 154.1 16.6 24.412 613.16 0.68 4 137.7 154.2 16.6 24.412 613.82 0.66 5 137.7 154.2 16.5 25.000 614.52 0.70 6 137.6 154.1 16.4 23.429 615.20 0.68 7 137.6 154.1 16.5 24.265 615.88 0.68 8 137.8 154 16.4 24.118 616.57 0.69 9 137.8 154 16.2 23.478 617.27 0.70 10 138 154.1 16.3 23.286 617.96 0.69 11 138.3 154.3 16.3 23.623 618.66 0.70 12 138.3 154.7 16.4 23.429 619.32 0.66 13 138.4 154.8 16.5 25.000 620.00 0.68 14 138.7 155 16.6 24.412 620.70 0.70 15 138.8 155.1 16.4 23.429 621.36 0.66 16 139 155.9 17.1 25.909 622.06 0.70 17 139.1 155.4 16.4 23.429 622.74 0.68 18 139.2 155.6 16.5 24.265 623.40 0.66 19 139.3 155.8 16.6 25.152 624.10 0.70 20 139.5 156 16.7 23.857 624.80 0.70 21 139.7 156.1 16.6 23.714 625.49 0.69 22 139.7 156.3 16.6 24.058 626.18 0.69 23 139.8 156.4 16.7 24.203 大中鋼鐵 記錄日期 中華民國106年9月6日 鍋爐效能記錄方式：
7. 18.182 20.238 19.318 19.767 18.605 19.767 20.000 77.778 0.000 21.951 15.094 20.000 20.000 19.540 20.930 19.318 20.455 19.767 19.540 28.571 0.000 0.000 16.393 16.842 18.889 19.101 19.101 19.767 20.225 0.000 13.750 17.978 17.978 18.391 45.161 0.000 0.000 77.778 12.903 18.391 17.978 48.387 0.000 0.000 0.000 11.828 17.045 16.667 16.667 92.308 0.000 19.512 14.545 18.182 19.540 19.101 19.318 19.101 71.429 12.931 19.388 19.565 20.455 20.455 20.455 21.348 21.591 21.111 21.591 20.000 20.225 20.225 21.348 20.455 20.455 21.591 21.591 21.839 21.348 21.839 21.591 21.111 21.348 21.591 21.591 21.111 21.591 20.000 20.225 21.591 21.111 19.388 24.051 21.591 21.591 21.591 20.879 21.348 21.348 21.111 45.946 0.000 0.000 0.000 14.286 19.318 19.101 45.455 0.000 0.000 0.000 16.667 18.182 20.000 42.857 20.455 20.930 20.455 20.930 48.571 0.000 0.000 17.742 18.391 19.767 19.318 19.767 20.000 20.482 20.690 20.690 20.455 21.176 21.111 21.839 22.619 21.348 22.619 20.455 20.690 20.455 20.690 20.690 21.176 21.591 21.429 20.455 20.690 20.690 22.093 20.690 21.839 21.839 21.839 21.591 22.093 21.591 21.839 22.093 22.892 21.111 22.093 22.093 21.348 22.093 22.353 21.839 22.989 22.093 21.839 22.353 21.111 21.111 22.093 21.839 22.093 21.839 21.591 22.093 22.093 22.727 22.727 22.619 23.256 21.348 23.256 22.093 20.455 21.839 22.353 21.591 34.545 0.000 0.000 20.000 18.824 20.690 19.318 20.000 21.176 20.225 20.455 20.930 20.455 20.455 50.000 0.000 0.000 33.333 14.773 18.605 18.605 18.605 53.571 0.000 0.000 16.000 15.306 19.767 19.767 19.318 19.767 20.000 19.318 20.455 18.889 20.238 25.714 0.000 0.000 17.391 17.778 18.391 19.767 19.540 20.455 30.000 0.000 0.000 16.949 17.204 20.455 19.767 19.318 19.318 20.455 19.101 21.429 0.000 0.000 30.000 13.725 19.101 18.391 19.318 17.978 17.778 19.767 31.579 0.000 0.000 16.129 16.667 19.540 17.978 19.318 19.318 78.947 0.000 0.000 16.129 16.854 19.540 19.540 32.000 0.000 0.000 80.000 14.444 18.605 18.889 18.391 42.857 0.000 0.000 17.308 16.129 19.767 19.318 19.101 19.540 19.318 61.538 0.000 0.000 13.235 16.667 18.182 18.391 19.767 18.182 19.540 24.286 0.000 0.000 33.333 13.542 18.182 17.978 18.391 18.182 19.767 20.455 19.318 21.429 18.182 17.213 18.033 18.400 18.699 18.548 18.699 20.175 24.419 23.333 22.989 22.727 22.093 22.472 23.256 21.348 21.591 21.839 20.225 145.455 0.000 0.000 14.286 19.318 21.429 20.225 20.455 76.190 0.000 13.265 19.767 19.318 19.101 20.000 106.250 0.000 0.000 12.941 18.182 19.101 20.000 20.690 25.714 0.000 0.000 14.493 16.505 19.355 19.780 22.093 20.930 20.455 21.839 21.591 21.591 21.348 21.429 16.854 19.540 19.318 20.455 27.692 0.000 0.000 29.032 15.957 19.540 19.767 20.000 19.101 136.364 0.000 0.000 13.636 19.540 18.182 19.101 26.984 0.000 0.000 0.000 0.000 16.364 16.092 42.424 0.000 0.000 0.000 0.000 10.937 14.773 325.000 0.000 0.000 0.000 0.000 0.000 10.959 17.073 16.667 18.824 17.442 18.391 0.000 0.000 0.000 12.500 16.471 18.605 18.182 19.048 136.364 0.000 28.571 16.393 16.935 17.073 16.800 18.033 17.742 17.742 18.548 17.742 17.054 17.886 17.600 17.886 18.033 18.548 18.548 17.742 18.033 18.548 16.923 18.548 18.852 18.699 18.400 19.355 18.852 18.548 18.852 18.254 17.969 18.548 18.852 18.254 18.852 18.548 18.852 18.548 18.548 18.852 17.969 19.355 18.548 18.852 18.548 18.033 18.400 19.008 17.742 18.033 17.424 18.033 17.742 18.033 18.400 18.699 18.852 18.699 17.742 17.886 17.188 18.033 17.460 18.033 18.852 18.548 18.852 17.460 18.852 18.852 17.692 18.548 18.033 17.742 19.167 18.110 18.852 18.699 19.672 18.254 17.969 17.742 19.492 22.222 21.111 20.455 20.000 20.000 20.225 20.225 19.565 20.000 19.101 19.101 18.889 19.101 18.000 21.250 19.101 19.318 18.085 19.318 18.889 93.750 0.000 266.667 12.121 18.182 17.778 17.978 17.204 17.978 20.482 0.000 0.000 25.000 13.265 16.000 20.253 17.978 17.021 18.391 17.978 19.318 18.889 18.182 18.182 18.889 18.889 19.318 19.565 20.455 19.318 18.889 19.318 19.318 18.889 20.455 18.889 19.540 19.355 20.455 20.455 20.000 20.455 20.225 20.225 19.101 19.540 19.318 19.565 18.889 19.318 18.889 19.318 20.225 19.101 19.318 19.540 19.101 57.143 0.000 0.000 13.750 17.045 17.045 28.571 0.000 0.000 43.750 12.766 17.045 18.182 18.182 300.000 0.000 116.667 12.791 15.556 17.045 16.304 0.000 50.000 100.000 150.000 200.000 250.000 300.000 350.000 0 100 200 300 400 500 600 700 節能設備安裝前數值分布圖1 18.182 20.238 19.318 19.767 18.605 19.767 20.000 21.951 15.094 20.000 20.000 19.540 20.930 19.318 20.455 19.767 19.540 28.571 16.393 16.842 18.889 19.101 19.101 19.767 20.225 13.750 17.978 17.978 18.391 45.161 12.903 18.391 17.978 48.387 11.828 17.045 16.667 16.667 19.512 14.545 18.182 19.540 19.101 19.318 19.101 12.931 19.388 19.565 20.455 20.455 20.455 21.348 21.591 21.111 21.591 20.000 20.225 20.225 21.348 20.455 20.455 21.591 21.591 21.839 21.348 21.839 21.591 21.111 21.348 21.591 21.591 21.111 21.591 20.000 20.225 21.591 21.111 19.388 24.051 21.591 21.591 21.591 20.879 21.348 21.348 21.111 45.946 14.286 19.318 19.101 45.455 16.667 18.182 20.000 42.857 20.455 20.930 20.455 20.930 48.571 17.742 18.391 19.767 19.318 19.767 20.000 20.482 20.690 20.690 20.455 21.176 21.111 21.839 22.619 21.348 22.619 20.455 20.690 20.455 20.690 20.690 21.176 21.591 21.429 20.455 20.690 20.690 22.093 20.690 21.839 21.839 21.839 21.591 22.093 21.591 21.839 22.093 22.892 21.111 22.093 22.093 21.348 22.093 22.353 21.839 22.989 22.093 21.839 22.353 21.111 21.111 22.093 21.839 22.093 21.839 21.591 22.093 22.093 22.727 22.727 22.619 23.256 21.348 23.256 22.093 20.455 21.839 22.353 21.591 34.545 20.000 18.824 20.690 19.318 20.000 21.176 20.225 20.455 20.930 20.455 20.455 33.333 14.773 18.605 18.605 18.605 16.000 15.306 19.767 19.767 19.318 19.767 20.000 19.318 20.455 18.889 20.238 25.714 17.391 17.778 18.391 19.767 19.540 20.455 30.000 16.949 17.204 20.455 19.767 19.318 19.318 20.455 19.101 21.429 30.000 13.725 19.101 18.391 19.318 17.978 17.778 19.767 31.579 16.129 16.667 19.540 17.978 19.318 19.318 16.129 16.854 19.540 19.540 32.000 14.444 18.605 18.889 18.391 42.857 17.308 16.129 19.767 19.318 19.101 19.540 19.318 13.235 16.667 18.182 18.391 19.767 18.182 19.540 24.286 33.333 13.542 18.182 17.978 18.391 18.182 19.767 20.455 19.318 21.429 18.182 17.213 18.033 18.400 18.699 18.548 18.699 20.175 24.419 23.333 22.989 22.727 22.093 22.472 23.256 21.348 21.591 21.839 20.225 14.286 19.318 21.429 20.225 20.455 13.265 19.767 19.318 19.101 20.000 12.941 18.182 19.101 20.000 20.690 25.714 14.493 16.505 19.355 19.780 22.093 20.930 20.455 21.839 21.591 21.591 21.348 21.429 16.854 19.540 19.318 20.455 27.692 29.032 15.957 19.540 19.767 20.000 19.101 13.636 19.540 18.182 19.101 26.984 16.364 16.092 42.424 10.937 14.773 10.959 17.073 16.667 18.824 17.442 18.391 12.500 16.471 18.605 18.182 19.048 28.571 16.393 16.935 17.073 16.800 18.033 17.742 17.742 18.548 17.742 17.054 17.886 17.600 17.886 18.033 18.548 18.548 17.742 18.033 18.548 16.923 18.548 18.852 18.699 18.400 19.355 18.852 18.548 18.852 18.254 17.969 18.548 18.852 18.254 18.852 18.548 18.852 18.548 18.548 18.852 17.969 19.355 18.548 18.852 18.548 18.033 18.400 19.008 17.742 18.033 17.424 18.033 17.742 18.033 18.400 18.699 18.852 18.699 17.742 17.886 17.188 18.033 17.460 18.033 18.852 18.548 18.852 17.460 18.852 18.852 17.692 18.548 18.033 17.742 19.167 18.110 18.852 18.699 19.672 18.254 17.969 17.742 19.492 22.222 21.111 20.455 20.000 20.000 20.225 20.225 19.565 20.000 19.101 19.101 18.889 19.101 18.000 21.250 19.101 19.318 18.085 19.318 18.889 12.121 18.182 17.778 17.978 17.204 17.978 20.482 25.000 13.265 16.000 20.253 17.978 17.021 18.391 17.978 19.318 18.889 18.182 18.182 18.889 18.889 19.318 19.565 20.455 19.318 18.889 19.318 19.318 18.889 20.455 18.889 19.540 19.355 20.455 20.455 20.000 20.455 20.225 20.225 19.101 19.540 19.318 19.565 18.889 19.318 18.889 19.318 20.225 19.101 19.318 19.540 19.101 13.750 17.045 17.045 28.571 43.750 12.766 17.045 18.182 18.182 12.791 15.556 17.045 16.304 19.981 0.000 10.000 20.000 30.000 40.000 50.000 60.000 0 100 200 300 400 500 600 700 節能設備安裝前數值分布圖2 平均值19.981 總筆數為609筆 由圖表顯示大部分落於0~50之 間 所以刪除0與50以上之數值(含50) 刪除後剩餘512筆 平均值為19.981 依統計學計算方式得出標準差數值為4.377 兩倍標準差以外數值需刪除即為 19.981-8.754=11.227 19.981+8.754=28.735 所以區間範圍為11.227度與28.735度,範圍外 數值即為異常值 刪除掉範圍外的數值後剩餘493筆 平均值為19.538 (一度瓦斯在一分鐘內升 高之溫度) 此數值即為節能設備安裝前之基準線 18.182 20.238 19.318 19.767 18.605 19.767 20.000 21.951 15.094 20.000 20.000 19.540 20.930 19.318 20.455 19.767 19.540 28.571 16.393 16.842 18.889 19.101 19.101 19.767 20.225 13.750 17.978 17.978 18.391 12.903 18.391 17.978 11.828 17.045 16.667 16.667 19.512 14.545 18.182 19.540 19.101 19.318 19.101 12.931 19.388 19.565 20.455 20.455 20.455 21.348 21.591 21.111 21.591 20.000 20.225 20.225 21.348 20.455 20.455 21.591 21.591 21.839 21.348 21.839 21.591 21.111 21.348 21.591 21.591 21.111 21.591 20.000 20.225 21.591 21.111 19.388 24.051 21.591 21.591 21.591 20.879 21.348 21.348 21.111 14.286 19.318 19.101 16.667 18.182 20.000 20.455 20.930 20.455 20.930 17.742 18.391 19.767 19.318 19.767 20.000 20.482 20.690 20.690 20.455 21.176 21.111 21.839 22.619 21.348 22.619 20.455 20.690 20.455 20.690 20.690 21.176 21.591 21.429 20.455 20.690 20.690 22.093 20.690 21.839 21.839 21.839 21.591 22.093 21.591 21.839 22.093 22.892 21.111 22.093 22.093 21.348 22.093 22.353 21.839 22.989 22.093 21.839 22.353 21.111 21.111 22.093 21.839 22.093 21.839 21.591 22.093 22.093 22.727 22.727 22.619 23.256 21.348 23.256 22.093 20.455 21.839 22.353 21.591 20.000 18.824 20.690 19.318 20.000 21.176 20.225 20.455 20.930 20.455 20.455 14.773 18.605 18.605 18.605 16.000 15.306 19.767 19.767 19.318 19.767 20.000 19.318 20.455 18.889 20.238 25.714 17.391 17.778 18.391 19.767 19.540 20.455 16.949 17.204 20.455 19.767 19.318 19.318 20.455 19.101 21.429 13.725 19.101 18.391 19.318 17.978 17.778 19.767 16.129 16.667 19.540 17.978 19.318 19.318 16.129 16.854 19.540 19.540 14.444 18.605 18.889 18.391 17.308 16.129 19.767 19.318 19.101 19.540 19.318 13.235 16.667 18.182 18.391 19.767 18.182 19.540 24.286 13.542 18.182 17.978 18.391 18.182 19.767 20.455 19.318 21.429 18.182 17.213 18.033 18.400 18.699 18.548 18.699 20.175 24.419 23.333 22.989 22.727 22.093 22.472 23.256 21.348 21.591 21.839 20.225 14.286 19.318 21.429 20.225 20.455 13.265 19.767 19.318 19.101 20.000 12.941 18.182 19.101 20.000 20.690 25.714 14.493 16.505 19.355 19.780 22.093 20.930 20.455 21.839 21.591 21.591 21.348 21.429 16.854 19.540 19.318 20.455 27.692 15.957 19.540 19.767 20.000 19.101 13.636 19.540 18.182 19.101 26.984 16.364 16.092 14.773 17.073 16.667 18.824 17.442 18.391 12.500 16.471 18.605 18.182 19.048 28.571 16.393 16.935 17.073 16.800 18.033 17.742 17.742 18.548 17.742 17.054 17.886 17.600 17.886 18.033 18.548 18.548 17.742 18.033 18.548 16.923 18.548 18.852 18.699 18.400 19.355 18.852 18.548 18.852 18.254 17.969 18.548 18.852 18.254 18.852 18.548 18.852 18.548 18.548 18.852 17.969 19.355 18.548 18.852 18.548 18.033 18.400 19.008 17.742 18.033 17.424 18.033 17.742 18.033 18.400 18.699 18.852 18.699 17.742 17.886 17.188 18.033 17.460 18.033 18.852 18.548 18.852 17.460 18.852 18.852 17.692 18.548 18.033 17.742 19.167 18.110 18.852 18.699 19.672 18.254 17.969 17.742 19.492 22.222 21.111 20.455 20.000 20.000 20.225 20.225 19.565 20.000 19.101 19.101 18.889 19.101 18.000 21.250 19.101 19.318 18.085 19.318 18.889 12.121 18.182 17.778 17.978 17.204 17.978 20.482 25.000 13.265 16.000 20.253 17.978 17.021 18.391 17.978 19.318 18.889 18.182 18.182 18.889 18.889 19.318 19.565 20.455 19.318 18.889 19.318 19.318 18.889 20.455 18.889 19.540 19.355 20.455 20.455 20.000 20.455 20.225 20.225 19.101 19.540 19.318 19.565 18.889 19.318 18.889 19.318 20.225 19.101 19.318 19.540 19.101 13.750 17.045 17.045 28.571 12.766 17.045 18.182 18.182 12.791 15.556 17.045 16.304 19.981 0.000 5.000 10.000 15.000 20.000 25.000 30.000 35.000 0 200 400 600 800 節能設備安裝前數值分布圖3 平均值19.538
8. 24.561 23.966 25.273 23.621 25.091 23.793 26.154 22.295 23.684 25.882 20.462 24.545 23.509 24.107 24.464 24.630 13.167 25.000 15.085 30.702 15.122 21.646 18.431 19.310 20.549 17.320 22.651 16.286 25.972 17.525 22.564 15.652 25.970 17.196 21.923 19.789 21.235 20.543 28.421 26.271 23.281 25.893 24.237 25.636 23.729 23.115 23.966 22.698 24.561 23.966 19.857 23.448 23.793 21.429 20.857 19.589 23.182 18.250 25.862 22.615 22.154 23.860 24.727 23.103 27.000 21.452 23.509 24.107 22.931 25.686 20.781 23.571 22.807 23.393 28.261 0.000 0.000 0.000 19.189 20.755 19.355 21.786 21.930 22.727 22.632 23.704 24.151 21.695 28.043 0.000 0.000 0.000 19.167 19.123 22.037 22.222 20.339 21.786 21.754 24.510 19.531 22.909 21.207 22.963 21.930 30.732 0.000 0.000 1775.000 19.947 18.065 20.526 21.250 16.500 17.766 17.674 20.649 18.025 24.426 21.846 25.000 19.853 21.429 23.966 20.746 23.387 17.683 25.862 17.294 28.113 17.831 22.698 20.833 24.407 23.559 22.712 21.270 13.689 22.262 17.019 21.294 14.628 25.278 15.041 24.267 15.500 23.421 17.232 19.474 18.000 15.000 17.031 19.386 16.493 18.417 17.823 21.058 24.675 17.025 23.718 0.000 0.000 12.805 25.789 25.439 25.172 28.462 24.032 25.254 23.077 25.500 18.846 15.118 24.471 16.050 23.077 16.333 20.000 16.532 18.099 18.051 19.286 18.584 19.211 18.889 17.851 20.097 16.960 21.735 17.436 27.534 16.179 26.533 16.098 24.872 16.975 23.415 17.982 22.093 17.982 19.688 20.192 18.900 20.900 18.800 22.826 16.930 24.881 16.471 25.732 16.341 26.282 16.475 27.162 17.288 26.400 19.320 25.000 22.674 20.000 27.812 26.508 27.759 27.368 26.897 27.018 26.897 26.724 28.364 25.833 25.763 25.833 25.246 21.370 27.119 20.658 24.687 18.681 24.242 18.989 22.817 26.190 19.750 25.625 19.518 28.103 20.909 26.780 23.478 22.464 23.582 21.408 25.161 22.353 26.897 21.233 28.909 21.528 25.574 14.068 18.440 18.700 16.341 17.222 16.977 17.823 17.559 18.833 18.279 18.160 20.000 17.903 18.689 18.095 19.496 20.446 19.649 19.913 19.565 17.829 19.167 18.934 19.153 18.387 20.180 18.678 20.177 19.000 20.727 18.992 24.146 16.667 26.986 15.690 26.528 15.546 29.839 19.767 27.797 21.333 26.271 26.607 25.965 25.172 25.439 24.068 23.898 23.279 23.279 22.500 23.833 24.655 24.000 25.263 24.098 24.667 25.690 21.429 26.552 22.029 25.424 22.029 26.667 19.359 26.552 20.526 25.000 22.083 25.410 21.781 22.254 27.931 22.941 26.724 21.081 24.839 23.485 23.594 22.754 23.231 24.918 20.986 26.271 20.411 24.677 18.171 26.724 20.411 26.545 22.187 23.226 24.407 23.065 23.833 23.500 22.951 23.279 23.607 24.576 22.540 22.742 24.138 22.258 22.667 22.295 21.774 23.220 22.131 22.833 21.406 22.623 23.000 23.000 22.623 23.000 22.951 23.000 23.621 21.746 22.581 23.333 23.500 23.000 22.623 23.220 22.419 23.729 23.333 22.258 22.258 22.258 23.966 23.167 22.742 24.237 23.279 23.500 23.500 22.903 23.443 23.115 23.667 23.500 22.419 23.167 23.559 22.623 23.333 23.065 23.833 22.667 14.857 16.870 16.957 17.143 17.350 17.177 17.460 17.619 16.567 17.760 17.857 18.016 19.000 30.145 16.555 29.429 16.500 28.429 15.520 26.301 17.807 24.177 19.808 21.011 20.808 19.785 22.556 18.300 23.837 16.875 27.123 15.966 27.536 15.528 27.206 15.750 24.211 18.426 21.786 26.250 24.576 26.250 25.345 25.517 25.862 22.388 26.842 24.918 23.065 25.167 25.410 27.500 25.763 26.491 23.538 25.932 26.071 23.651 23.750 21.831 27.069 24.462 25.246 24.091 27.119 24.921 24.921 27.544 22.985 26.379 24.516 25.763 26.667 24.127 25.833 24.754 25.333 24.667 23.906 25.167 23.538 24.355 23.906 22.388 20.385 22.537 21.940 22.239 23.692 23.750 25.833 26.491 25.254 22.727 25.517 23.651 24.590 24.032 21.791 26.140 25.085 23.710 14.862 17.009 21.176 16.610 22.593 18.519 19.053 20.510 18.571 23.182 17.524 24.268 16.195 27.027 16.000 26.216 15.492 27.910 15.917 25.139 17.091 23.026 17.757 23.333 18.000 21.220 18.835 20.115 22.045 18.632 23.951 17.600 23.875 16.296 25.270 15.478 26.714 16.579 26.176 17.207 23.684 16.393 20.800 16.880 22.857 16.270 19.815 17.049 19.643 18.362 18.718 19.906 18.136 21.212 17.190 19.820 17.807 19.115 15.581 22.766 21.789 16.800 22.268 17.190 19.818 18.644 17.965 25.741 18.052 25.849 21.364 14.019 24.493 14.261 24.000 15.841 20.361 18.600 19.529 23.077 26.786 25.926 25.185 25.094 24.906 24.259 22.807 25.000 23.273 24.615 23.091 24.231 23.519 23.962 23.333 23.396 22.727 22.727 23.774 23.148 24.038 22.364 23.208 22.593 23.396 22.963 22.364 22.963 23.396 23.148 22.727 23.585 23.148 23.585 22.963 23.208 21.754 23.269 22.364 23.654 22.963 23.396 23.019 22.000 22.642 22.000 22.222 21.636 22.453 21.818 22.885 21.636 22.500 21.667 21.852 250.000 0.000 0.000 22.121 20.189 21.667 22.264 22.075 21.667 22.075 21.481 20.714 20.909 22.308 21.296 22.308 21.273 22.885 21.273 13.529 23.485 15.745 19.320 17.596 20.204 17.048 24.730 15.315 28.333 17.071 24.000 21.690 25.636 22.419 22.121 17.531 22.687 14.107 23.158 14.034 21.975 15.207 19.773 18.544 17.576 20.426 16.239 22.353 15.085 22.326 15.167 23.671 16.542 24.697 20.122 19.737 23.030 21.029 25.926 23.158 23.818 21.695 23.091 22.143 22.593 21.786 21.636 21.455 21.053 21.636 21.250 21.250 20.877 22.407 29.268 26.591 0.000 0.000 0.000 18.235 22.558 18.033 20.926 20.714 21.887 21.091 21.667 32.500 156.667 69.000 325.000 81.818 15.088 19.259 18.750 19.815 19.818 20.943 19.643 20.943 28.718 86.000 0.000 0.000 16.111 16.429 19.057 19.091 20.000 19.286 21.154 19.649 19.464 21.111 21.296 21.296 20.545 20.943 20.000 21.731 20.364 20.702 21.111 21.455 21.852 21.455 22.453 21.818 23.019 21.429 22.453 23.077 0.000 200.000 400.000 600.000 800.000 1000.000 1200.000 1400.000 1600.000 1800.000 2000.000 0 200 400 600 800 1000 節能設備安裝後數值分布圖1 24.561 23.966 25.273 23.621 25.091 23.793 26.154 22.295 23.684 25.882 20.462 24.545 23.509 24.107 24.464 24.630 13.167 25.000 15.085 30.702 15.122 21.646 18.431 19.310 20.549 17.320 22.651 16.286 25.972 17.525 22.564 15.652 25.970 17.196 21.923 19.789 21.235 20.543 28.421 26.271 23.281 25.893 24.237 25.636 23.729 23.115 23.966 22.698 24.561 23.966 19.857 23.448 23.793 21.429 20.857 19.589 23.182 18.250 25.862 22.615 22.154 23.860 24.727 23.103 27.000 21.452 23.509 24.107 22.931 25.686 20.781 23.571 22.807 23.393 28.261 19.189 20.755 19.355 21.786 21.930 22.727 22.632 23.704 24.151 21.695 28.043 19.167 19.123 22.037 22.222 20.339 21.786 21.754 24.510 19.531 22.909 21.207 22.963 21.930 30.732 19.947 18.065 20.526 21.250 16.500 17.766 17.674 20.649 18.025 24.426 21.846 25.000 19.853 21.429 23.966 20.746 23.387 17.683 25.862 17.294 28.113 17.831 22.698 20.833 24.407 23.559 22.712 21.270 13.689 22.262 17.019 21.294 14.628 25.278 15.041 24.267 15.500 23.421 17.232 19.474 18.000 15.000 17.031 19.386 16.493 18.417 17.823 21.058 24.675 17.025 23.718 12.805 25.789 25.439 25.172 28.462 24.032 25.254 23.077 25.500 18.846 15.118 24.471 16.050 23.077 16.333 20.000 16.532 18.099 18.051 19.286 18.584 19.211 18.889 17.851 20.097 16.960 21.735 17.436 27.534 16.179 26.533 16.098 24.872 16.975 23.415 17.982 22.093 17.982 19.688 20.192 18.900 20.900 18.800 22.826 16.930 24.881 16.471 25.732 16.341 26.282 16.475 27.162 17.288 26.400 19.320 25.000 22.674 20.000 27.812 26.508 27.759 27.368 26.897 27.018 26.897 26.724 28.364 25.833 25.763 25.833 25.246 21.370 27.119 20.658 24.687 18.681 24.242 18.989 22.817 26.190 19.750 25.625 19.518 28.103 20.909 26.780 23.478 22.464 23.582 21.408 25.161 22.353 26.897 21.233 28.909 21.528 25.574 14.068 18.440 18.700 16.341 17.222 16.977 17.823 17.559 18.833 18.279 18.160 20.000 17.903 18.689 18.095 19.496 20.446 19.649 19.913 19.565 17.829 19.167 18.934 19.153 18.387 20.180 18.678 20.177 19.000 20.727 18.992 24.146 16.667 26.986 15.690 26.528 15.546 29.839 19.767 27.797 21.333 26.271 26.607 25.965 25.172 25.439 24.068 23.898 23.279 23.279 22.500 23.833 24.655 24.000 25.263 24.098 24.667 25.690 21.429 26.552 22.029 25.424 22.029 26.667 19.359 26.552 20.526 25.000 22.083 25.410 21.781 22.254 27.931 22.941 26.724 21.081 24.839 23.485 23.594 22.754 23.231 24.918 20.986 26.271 20.411 24.677 18.171 26.724 20.411 26.545 22.187 23.226 24.407 23.065 23.833 23.500 22.951 23.279 23.607 24.576 22.540 22.742 24.138 22.258 22.667 22.295 21.774 23.220 22.131 22.833 21.406 22.623 23.000 23.000 22.623 23.000 22.951 23.000 23.621 21.746 22.581 23.333 23.500 23.000 22.623 23.220 22.419 23.729 23.333 22.258 22.258 22.258 23.966 23.167 22.742 24.237 23.279 23.500 23.500 22.903 23.443 23.115 23.667 23.500 22.419 23.167 23.559 22.623 23.333 23.065 23.833 22.667 14.857 16.870 16.957 17.143 17.350 17.177 17.460 17.619 16.567 17.760 17.857 18.016 19.000 30.145 16.555 29.429 16.500 28.429 15.520 26.301 17.807 24.177 19.808 21.011 20.808 19.785 22.556 18.300 23.837 16.875 27.123 15.966 27.536 15.528 27.206 15.750 24.211 18.426 21.786 26.250 24.576 26.250 25.345 25.517 25.862 22.388 26.842 24.918 23.065 25.167 25.410 27.500 25.763 26.491 23.538 25.932 26.071 23.651 23.750 21.831 27.069 24.462 25.246 24.091 27.119 24.921 24.921 27.544 22.985 26.379 24.516 25.763 26.667 24.127 25.833 24.754 25.333 24.667 23.906 25.167 23.538 24.355 23.906 22.388 20.385 22.537 21.940 22.239 23.692 23.750 25.833 26.491 25.254 22.727 25.517 23.651 24.590 24.032 21.791 26.140 25.085 23.710 14.862 17.009 21.176 16.610 22.593 18.519 19.053 20.510 18.571 23.182 17.524 24.268 16.195 27.027 16.000 26.216 15.492 27.910 15.917 25.139 17.091 23.026 17.757 23.333 18.000 21.220 18.835 20.115 22.045 18.632 23.951 17.600 23.875 16.296 25.270 15.478 26.714 16.579 26.176 17.207 23.684 16.393 20.800 16.880 22.857 16.270 19.815 17.049 19.643 18.362 18.718 19.906 18.136 21.212 17.190 19.820 17.807 19.115 15.581 22.766 21.789 16.800 22.268 17.190 19.818 18.644 17.965 25.741 18.052 25.849 21.364 14.019 24.493 14.261 24.000 15.841 20.361 18.600 19.529 23.077 26.786 25.926 25.185 25.094 24.906 24.259 22.807 25.000 23.273 24.615 23.091 24.231 23.519 23.962 23.333 23.396 22.727 22.727 23.774 23.148 24.038 22.364 23.208 22.593 23.396 22.963 22.364 22.963 23.396 23.148 22.727 23.585 23.148 23.585 22.963 23.208 21.754 23.269 22.364 23.654 22.963 23.396 23.019 22.000 22.642 22.000 22.222 21.636 22.453 21.818 22.885 21.636 22.500 21.667 21.852 22.121 20.189 21.667 22.264 22.075 21.667 22.075 21.481 20.714 20.909 22.308 21.296 22.308 21.273 22.885 21.273 13.529 23.485 15.745 19.320 17.596 20.204 17.048 24.730 15.315 28.333 17.071 24.000 21.690 25.636 22.419 22.121 17.531 22.687 14.107 23.158 14.034 21.975 15.207 19.773 18.544 17.576 20.426 16.239 22.353 15.085 22.326 15.167 23.671 16.542 24.697 20.122 19.737 23.030 21.029 25.926 23.158 23.818 21.695 23.091 22.143 22.593 21.786 21.636 21.455 21.053 21.636 21.250 21.250 20.877 22.407 29.268 26.591 18.235 22.558 18.033 20.926 20.714 21.887 21.091 21.667 32.500 15.088 19.259 18.750 19.815 19.818 20.943 19.643 20.943 28.718 16.111 16.429 19.057 19.091 20.000 19.286 21.154 19.649 19.464 21.111 21.296 21.296 20.545 20.943 20.000 21.731 20.364 20.702 21.111 21.455 21.852 21.455 22.453 21.818 23.019 21.429 22.453 23.077 0.000 5.000 10.000 15.000 20.000 25.000 30.000 35.000 0 200 400 600 800 1000 節能設備安裝後數值分布圖2 平均值21.897 溫 總筆數為780筆 由圖表顯示大部分落於0~50之 間 所以刪除0與50以上之數值(含50) 刪除後剩餘756筆 平均值為21.897 依統計學計算方式得出標準差數值為3.368 兩倍標準差以外數值需刪除即為 21.897-6.736=15.161 21.897+6.736=28.633 所以區間範圍為15.161度與28.633度,範圍外 數值即為異常值 刪除掉範圍外的數值後剩餘728筆 平均值為21.906 (一度瓦斯在一分鐘內升 高之溫度) 此數值即為節能設備安裝後之基準線 24.561 23.966 25.273 23.621 25.091 23.793 26.154 22.295 23.684 25.882 20.462 24.545 23.509 24.107 24.464 24.630 25.000 21.646 18.431 19.310 20.549 17.320 22.651 16.286 25.972 17.525 22.564 15.652 25.970 17.196 21.923 19.789 21.235 20.543 28.421 26.271 23.281 25.893 24.237 25.636 23.729 23.115 23.966 22.698 24.561 23.966 19.857 23.448 23.793 21.429 20.857 19.589 23.182 18.250 25.862 22.615 22.154 23.860 24.727 23.103 27.000 21.452 23.509 24.107 22.931 25.686 20.781 23.571 22.807 23.393 28.261 19.189 20.755 19.355 21.786 21.930 22.727 22.632 23.704 24.151 21.695 28.043 19.167 19.123 22.037 22.222 20.339 21.786 21.754 24.510 19.531 22.909 21.207 22.963 21.930 19.947 18.065 20.526 21.250 16.500 17.766 17.674 20.649 18.025 24.426 21.846 25.000 19.853 21.429 23.966 20.746 23.387 17.683 25.862 17.294 28.113 17.831 22.698 20.833 24.407 23.559 22.712 21.270 22.262 17.019 21.294 25.278 24.267 15.500 23.421 17.232 19.474 18.000 17.031 19.386 16.493 18.417 17.823 21.058 24.675 17.025 23.718 25.789 25.439 25.172 28.462 24.032 25.254 23.077 25.500 18.846 24.471 16.050 23.077 16.333 20.000 16.532 18.099 18.051 19.286 18.584 19.211 18.889 17.851 20.097 16.960 21.735 17.436 27.534 16.179 26.533 16.098 24.872 16.975 23.415 17.982 22.093 17.982 19.688 20.192 18.900 20.900 18.800 22.826 16.930 24.881 16.471 25.732 16.341 26.282 16.475 27.162 17.288 26.400 19.320 25.000 22.674 20.000 27.812 26.508 27.759 27.368 26.897 27.018 26.897 26.724 28.364 25.833 25.763 25.833 25.246 21.370 27.119 20.658 24.687 18.681 24.242 18.989 22.817 26.190 19.750 25.625 19.518 28.103 20.909 26.780 23.478 22.464 23.582 21.408 25.161 22.353 26.897 21.233 21.528 25.574 18.440 18.700 16.341 17.222 16.977 17.823 17.559 18.833 18.279 18.160 20.000 17.903 18.689 18.095 19.496 20.446 19.649 19.913 19.565 17.829 19.167 18.934 19.153 18.387 20.180 18.678 20.177 19.000 20.727 18.992 24.146 16.667 26.986 15.690 26.528 15.546 19.767 27.797 21.333 26.271 26.607 25.965 25.172 25.439 24.068 23.898 23.279 23.279 22.500 23.833 24.655 24.000 25.263 24.098 24.667 25.690 21.429 26.552 22.029 25.424 22.029 26.667 19.359 26.552 20.526 25.000 22.083 25.410 21.781 22.254 27.931 22.941 26.724 21.081 24.839 23.485 23.594 22.754 23.231 24.918 20.986 26.271 20.411 24.677 18.171 26.724 20.411 26.545 22.187 23.226 24.407 23.065 23.833 23.500 22.951 23.279 23.607 24.576 22.540 22.742 24.138 22.258 22.667 22.295 21.774 23.220 22.131 22.833 21.406 22.623 23.000 23.000 22.623 23.000 22.951 23.000 23.621 21.746 22.581 23.333 23.500 23.000 22.623 23.220 22.419 23.729 23.333 22.258 22.258 22.258 23.966 23.167 22.742 24.237 23.279 23.500 23.500 22.903 23.443 23.115 23.667 23.500 22.419 23.167 23.559 22.623 23.333 23.065 23.833 22.667 16.870 16.957 17.143 17.350 17.177 17.460 17.619 16.567 17.760 17.857 18.016 19.000 16.555 16.500 28.429 15.520 26.301 17.807 24.177 19.808 21.011 20.808 19.785 22.556 18.300 23.837 16.875 27.123 15.966 27.536 15.528 27.206 15.750 24.211 18.426 21.786 26.250 24.576 26.250 25.345 25.517 25.862 22.388 26.842 24.918 23.065 25.167 25.410 27.500 25.763 26.491 23.538 25.932 26.071 23.651 23.750 21.831 27.069 24.462 25.246 24.091 27.119 24.921 24.921 27.544 22.985 26.379 24.516 25.763 26.667 24.127 25.833 24.754 25.333 24.667 23.906 25.167 23.538 24.355 23.906 22.388 20.385 22.537 21.940 22.239 23.692 23.750 25.833 26.491 25.254 22.727 25.517 23.651 24.590 24.032 21.791 26.140 25.085 23.710 17.009 21.176 16.610 22.593 18.519 19.053 20.510 18.571 23.182 17.524 24.268 16.195 27.027 16.000 26.216 15.492 27.910 15.917 25.139 17.091 23.026 17.757 23.333 18.000 21.220 18.835 20.115 22.045 18.632 23.951 17.600 23.875 16.296 25.270 15.478 26.714 16.579 26.176 17.207 23.684 16.393 20.800 16.880 22.857 16.270 19.815 17.049 19.643 18.362 18.718 19.906 18.136 21.212 17.190 19.820 17.807 19.115 15.581 22.766 21.789 16.800 22.268 17.190 19.818 18.644 17.965 25.741 18.052 25.849 21.364 24.493 24.000 15.841 20.361 18.600 19.529 23.077 26.786 25.926 25.185 25.094 24.906 24.259 22.807 25.000 23.273 24.615 23.091 24.231 23.519 23.962 23.333 23.396 22.727 22.727 23.774 23.148 24.038 22.364 23.208 22.593 23.396 22.963 22.364 22.963 23.396 23.148 22.727 23.585 23.148 23.585 22.963 23.208 21.754 23.269 22.364 23.654 22.963 23.396 23.019 22.000 22.642 22.000 22.222 21.636 22.453 21.818 22.885 21.636 22.500 21.667 21.852 22.121 20.189 21.667 22.264 22.075 21.667 22.075 21.481 20.714 20.909 22.308 21.296 22.308 21.273 22.885 21.273 23.485 15.745 19.320 17.596 20.204 17.048 24.730 15.315 28.333 17.071 24.000 21.690 25.636 22.419 22.121 17.531 22.687 23.158 21.975 15.207 19.773 18.544 17.576 20.426 16.239 22.353 22.326 15.167 23.671 16.542 24.697 20.122 19.737 23.030 21.029 25.926 23.158 23.818 21.695 23.091 22.143 22.593 21.786 21.636 21.455 21.053 21.636 21.250 21.250 20.877 22.407 26.591 18.235 22.558 18.033 20.926 20.714 21.887 21.091 21.667 19.259 18.750 19.815 19.818 20.943 19.643 20.943 16.111 16.429 19.057 19.091 20.000 19.286 21.154 19.649 19.464 21.111 21.296 21.296 20.545 20.943 20.000 21.731 20.364 20.702 21.111 21.455 21.852 21.455 22.453 21.818 23.019 21.429 22.453 23.077 0.000 5.000 10.000 15.000 20.000 25.000 30.000 0 200 400 600 800 1000 節能設備安裝後數值分布圖3 平均值21.906
9. 節能率統計： 計算方式: (安裝天然氣節能設備後基線-安裝天然氣設備前基線)/安裝天然氣設備前基線*%=節能率 (21.906-19.538)/19.538*100%=12.12% 安裝前燃燒測試情況 測試日期 2013/12/12~2014/01/06 每度天然氣可升高溫度 19.538度(每分鐘) 安裝後燃燒測試情況 測試日期 2014/02/21~2014/04/08 每度天然氣可升高溫度 21.906度(每分鐘)
10. 平均 11.07% 實際產量與用量統計：(客戶提供)
11. 每年節省瓦斯費計算： 鋼廠150萬Kcal熱媒鍋爐: 安裝後瓦斯費用約為150萬元 月省瓦斯費約: (150萬/(1-12.12%))-150萬=20.69萬元 年省瓦斯費約: 20.69萬元*12月=248.28萬元 減少碳排放量概算 每月減少天然氣用量約10,345度(30天/24小時) 天然氣每立方米約為2.09碳排放量 -10,345*2.09*12(月)=-259,452.6 Kg=-259公噸 (年減少碳排放量)
12. 化工廠蒸氣鍋爐︰ 鍋爐規格：臥式，10.8噸 and 6噸 並聯使用(難度較單台使用高) 鍋爐應用：製程加熱 燃燒機 ：台製、熱空氣回收75 ℃、 鼓風機馬力 30HP and 20HP 10.8噸 6噸
13. 安裝後照片： 數據擷取設備組 氣水分離式設備 空氣設備 比原管道截面 積放大8-10倍 安裝完成照 瓦斯設備 三通設計 蒸氣流量計
14. 14 日期 時間(每小 時一筆) 10.8T水表 10.8T瓦斯表 6T水表 6T瓦斯表 10.8T蒸氣量 6T蒸氣量 10.8T(每度瓦斯所 生產蒸氣量) 6T(每度瓦斯所 生產蒸氣量) 10.8T(每度瓦斯所 消耗水量) 6T(每度瓦斯所 消耗水量) 8月1日 0 3.67 129.3 0.681 30.1 3141.541 568.327 24.2965 18.8813 0.0284 0.0226 1 0 1.4 2.917 128.2 23.067 2883.58 16.4764 22.4928 0.0000 0.0228 2 0 1.4 0 0 0 50.328 0.0000 #DIV/0! 0.0000 #DIV/0! 3 0 1.4 0 0 0 41.94 0.0000 #DIV/0! 0.0000 #DIV/0! 4 3.186 162.7 2.562 122.8 3407.869 2646.604 20.9457 21.5521 0.0196 0.0209 5 3.533 157.2 3.078 122.5 3711.959 2864.706 23.6130 23.3854 0.0225 0.0251 6 1.086 31.4 1.109 38.6 673.185 878.702 21.4390 22.7643 0.0346 0.0287 7 3.105 91.8 1.828 26.3 1931.472 700.45 21.0400 26.6331 0.0338 0.0695 8 1.098 35 2.398 131 840.958 2686.446 24.0274 20.5072 0.0314 0.0183 9 0 38.8 2.14 89.8 608.173 2021.65 15.6746 22.5128 0.0000 0.0238 10 3.486 157.3 3.012 131.5 3670.018 3042.969 23.3313 23.1404 0.0222 0.0229 11 3.582 157.5 2.554 118.7 3617.589 2799.693 22.9688 23.5863 0.0227 0.0215 12 0.925 10 3.045 129.3 304.085 2967.47 30.4085 22.9503 0.0925 0.0235 13 0 1.4 3.326 145.5 0 3466.584 0.0000 23.8253 0.0000 0.0229 14 0 1.4 0.767 41.5 0 910.161 0.0000 21.9316 0.0000 0.0185 15 0 1.4 0.436 0 0 41.94 0.0000 #DIV/0! 0.0000 #DIV/0! 16 2.17 121.2 1.59 94.7 2365.591 1975.516 19.5181 20.8608 0.0179 0.0168 17 3.534 157 2.916 125.3 3703.572 2938.111 23.5896 23.4486 0.0225 0.0233 18 2.308 104.2 1.834 83.8 2277.505 1853.882 21.8571 22.1227 0.0221 0.0219 19 0 1.4 2.373 116.3 224.394 2782.918 160.2814 23.9288 0.0000 0.0204 20 0 1.4 3.568 155.1 2.097 3552.569 1.4979 22.9050 0.0000 0.0230 21 2.469 15.2 1.883 44.6 100.664 1040.186 6.6226 23.3226 0.1624 0.0422 22 3.492 167.9 2.951 138.8 3678.403 2946.495 21.9083 21.2284 0.0208 0.0213 23 3.4 156.9 2.98 122.9 3690.991 2854.218 23.5245 23.2239 0.0217 0.0242 鍋爐效能記錄方式：
15. 總紀錄517小時 每度瓦斯所產生蒸氣量為20.9446KG (採用統計學方式計算 兩倍標準差) 總紀錄577小時 每度瓦斯所產生蒸氣量為23.1172KG (採用統計學方式計算 兩倍標準差) 前基線 20.9664/1.674=12.5117KG 後基線 23.1174/1.674=13.8096KG 節能率 (13.8096-12.5117)/12.5117=10.53% 壓力係數 1.674
16. 10.8噸蒸氣鍋爐節能率計算結果： 量測統計數據 計算方式︰ (安裝天然氣節能設備後鍋爐基線－未安裝天然氣節能設備前鍋爐基線) ÷ (未安裝天然氣節 能設備前鍋爐基線) x 100％ = 節能率 計算結果︰ (13.8296-12.5117)/12.5117*100%=10.53% 量測時間 每度瓦斯所生產蒸氣量(均值) 量測時間 壓力係數 每度瓦斯所生產蒸氣量(均值) 1.674 後基線 前基線 23.1508 13.8296(壓力係數) 106/8/01~106/8/24 106/06/20~106/07/15 20.9446 12.5117(壓力係數) 10.8T蒸氣鍋爐
17. 總紀錄517小時 每度瓦斯所產生蒸氣量為20.7090KG (採用統計學方式計算 兩倍標準差) 總紀錄577小時 每度瓦斯所產生蒸氣量為23.0094KG (採用統計學方式計算 兩倍標準差) 前基線 20.7090/1.674=12.3710KG 後基線 23.1174/1.674=13.7452KG 節能率 (13.7452-12.3710)/12.3710=11.11% 壓力係數 1.674
18. 6噸蒸氣鍋爐節能率計算結果： 量測統計數據 計算方式︰ (安裝天然氣節能設備後鍋爐基線－未安裝天然氣節能設備前鍋爐基線) ÷ (未安裝天然氣節 能設備前鍋爐基線) x 100％ = 節能率節能率 計算結果︰ (13.7452-12.3710)/12.3710*100%=11.11% 量測時間 每度瓦斯所生產蒸氣量(均值) 量測時間 壓力係數 每度瓦斯所生產蒸氣量(均值) 1.674 後基線 106/8/01~106/8/24 23.0094 13.7452(壓力係數) 6T蒸氣鍋爐 前基線 106/06/20~106/07/15 20.7090 12.3710(壓力係數)
19. 106年節省天然氣費概算 10.8噸和6噸蒸氣鍋爐: 安裝後瓦斯費用約為297萬元 月省天然氣費約: (297萬/(1-10%))-297萬=33萬元 年省天然氣費約: 33萬*12月=396萬元 減少碳排放量概算 每月減少天然氣用量約23,571.4度 天然氣每立方米約為2.09碳排放量 -23,571.4*2.09*12(月)=-591,171.43 Kg (年減少碳排放量)
20. 20 化工廠 蒸氣鍋爐節能效率紀錄 期 間 106/08/21~09/20 106/09/21~10/20 106/10/21~11/20 監測效率 監測效率 監測效率 10.8T 10.14% 10.01% 12.99% 6T 12.41% 12.27% 13.31% 日期 時間(每小 時一筆) 10.8T水表 10.8T瓦斯表 6T水表 6T瓦斯表 10.8T蒸氣量 6T蒸氣量 10.8T(每度瓦斯所生 產蒸氣量) 6T(每度瓦斯所生 產蒸氣量) 10.8T(每度瓦斯所消 耗水量) 6T(每度瓦斯所消 耗水量) 8月21日 0 4.088 176.7 3.4 145.5 4135.586 3359.639 23.4046 23.0903 0.0231 0.0234 1 3.879 158 3.199 130.6 3753.899 3057.643 23.7589 23.4123 0.0246 0.0245 2 0 20.9 0.211 13.3 427.816 278.92 20.4697 20.9714 0.0000 0.0159 3 0 1.5 0 0 29.358 12.582 19.5720 #DIV/0! 0.0000 #DIV/0! 4 3.238 156.3 2.156 98.5 3342.86 2090.857 21.3875 21.2270 0.0207 0.0219 5 3.575 157.2 1.949 82.8 3607.102 1929.378 22.9459 23.3017 0.0227 0.0235 6 2.3 92.4 1.498 52.2 2113.926 1153.432 22.8780 22.0964 0.0249 0.0287 7 2.32 105.8 2.43 97.9 2587.887 2296.378 24.4602 23.4564 0.0219 0.0248 8 3.985 176.3 2.711 120.2 4085.254 2812.28 23.1722 23.3967 0.0226 0.0226 9 2.07 103 1.627 81.1 2390.755 1879.046 23.2112 23.1695 0.0201 0.0201 10 3.495 153.3 3.102 127.4 3539.991 2860.509 23.0919 22.4530 0.0228 0.0243 11 3.505 156.2 2.675 118.6 3598.718 2766.139 23.0392 23.3233 0.0224 0.0226 12 3.804 158.8 2.869 124.6 3737.126 2948.595 23.5335 23.6645 0.0240 0.0230 13 2.777 158.2 3.415 139.3 3711.96 3175.088 23.4637 22.7932 0.0176 0.0245 14 2.315 88.7 1.834 71.7 1900.018 1579.156 21.4207 22.0245 0.0261 0.0256 15 0 1.5 0 0 37.746 14.679 25.1640 #DIV/0! 0.0000 #DIV/0! 16 2.391 127 2.332 108.9 2889.872 2365.588 22.7549 21.7226 0.0188 0.0214 17 3.656 156.9 2.454 119.4 3619.687 2837.446 23.0700 23.7642 0.0233 0.0206 18 2.393 104.1 1.492 63.2 2290.09 1417.671 21.9989 22.4315 0.0230 0.0236 19 2.088 90.2 1.906 85.5 2092.957 1914.701 23.2035 22.3942 0.0231 0.0223 20 3.667 161.7 3.222 133 3808.426 3059.741 23.5524 23.0056 0.0227 0.0242 21 2.043 113.5 1.8 72.1 2638.214 1784.673 23.2442 24.7527 0.0180 0.0250 22 4.016 161.2 2.583 123.1 3686.799 2854.22 22.8710 23.1862 0.0249 0.0210 23 2.959 151.3 2.757 114.5 3670.016 2705.325 24.2565 23.6273 0.0196 0.0241 8月22日 0 3.678 165.8 3.038 136.6 3808.427 3128.949 22.9700 22.9059 0.0222 0.0222 1 3.1 157.8 3.043 131.2 3716.152 3030.378 23.5498 23.0974 0.0196 0.0232 2 1.082 46.3 1.03 31 918.548 654.312 19.8390 21.1068 0.0234 0.0332 3 0 1.6 0 0 46.134 6.291 28.8338 #DIV/0! 0.0000 #DIV/0! 4 2.969 124.5 2.055 94.4 2684.355 2132.802 21.5611 22.5932 0.0238 0.0218 5 3.442 156.7 2.836 118.9 3565.161 2751.462 22.7515 23.1410 0.0220 0.0239 6 2.222 61.1 1.022 50.8 1463.808 1210.053 23.9576 23.8199 0.0364 0.0201 7 3.367 89.7 3.032 119.9 1606.419 2701.131 17.9088 22.5282 0.0375 0.0253 8 3.605 157.5 3.465 142 3628.072 3214.931 23.0354 22.6404 0.0229 0.0244 9 2.243 123.3 2.372 87.3 2952.79 2090.859 23.9480 23.9503 0.0182 0.0272 10 3.336 155.7 2.572 121.4 3531.607 2787.106 22.6821 22.9580 0.0214 0.0212 11 3.32 155.9 2.586 116.4 3514.827 2663.371 22.5454 22.8812 0.0213 0.0222 12 3.023 135.8 3.357 133 3275.752 3074.424 24.1219 23.1160 0.0223 0.0252 13 3.635 155.9 3.279 138.1 3628.074 3223.321 23.2718 23.3405 0.0233 0.0237 14 1.824 103.8 1.862 76.8 2319.452 1686.109 22.3454 21.9545 0.0176 0.0242 15 1.027 1.5 0 0 239.075 241.171 159.3833 #DIV/0! 0.6847 #DIV/0! 16 1.996 122.4 2.045 101.5 2445.277 2088.762 19.9778 20.5789 0.0163 0.0201 17 3.442 155.5 2.695 117.6 3560.963 2707.414 22.9001 23.0222 0.0221 0.0229 18 3.726 144.4 1.377 63.2 3326.081 1526.724 23.0338 24.1570 0.0258 0.0218 監測軟體 Anydesk 統計報表每月21號至次月20號
21. 21 106年12月 安裝後 蒸氣量 蒸氣量(壓力系數) 壓力係數 平均值 24.0504 14.36699806 1.674 安裝前 蒸氣量 蒸氣量(壓力系數) 平均值 20.945 12.51170848 節能率 (14.3670-12.5117)/12.5117=14.83% 安裝後 蒸氣量 蒸氣量(壓力系數) 壓力係數 平均值 23.3261 13.93437442 1.674 安裝前 蒸氣量 蒸氣量(壓力系數) 平均值 20.709 12.37096774 節能率 (13.9344-12.3710)/12.3710=12.64% 0.0000 5.0000 10.0000 15.0000 20.0000 25.0000 30.0000 0 100 200 300 400 500 600 700 800 10.8T後基線(每度瓦斯所生產蒸氣量) 10.8T(每度瓦斯所生產蒸氣量) 0.0000 5.0000 10.0000 15.0000 20.0000 25.0000 30.0000 0 100 200 300 400 500 600 700 800 6T後基線(每度瓦斯所生產蒸氣量) 6T(每度瓦斯所生產蒸氣量) 0.0000 5.0000 10.0000 15.0000 20.0000 25.0000 30.0000 0 100 200 300 400 500 600 700 800 10.8T後基線(每度瓦斯所生產蒸氣量) 10.8T(每度瓦斯所生產蒸氣量) 持續記錄中…
22. 22 橡膠廠熱媒鍋爐︰ 鍋爐規格：臥式，300萬Kcal熱媒 鍋爐應用：製程加熱 燃燒機 ：台製、熱空氣回收130 ℃、 鼓風機馬力 20HP 300萬Kcal熱媒
23. 23 橡膠廠熱媒鍋爐︰節能設備安裝後照片 空氣端節能設備 瓦斯端節能設備
24. 24 橡膠廠熱媒鍋爐︰安裝後照片 遠端數據擷取設備
25. 25 鍋爐即時監控系統 鍋爐能耗報表自動產出
26. 26 前基線 後基線
27. 27 節能率計算 每年節省瓦斯費計算： 橡膠300萬Kcal熱媒鍋爐: 安裝後瓦斯費用約為160萬元 月省瓦斯費約: (160萬/(1-12.12%))-160萬=22.07萬元 年省瓦斯費約: 22.07萬元*12月=264.84萬元 減少碳排放量概算 每月減少天然氣用量約14,000度(30天/24小時) 天然氣每立方米約為2.09kg碳排放量 14,000 *2.09*12(月)=351,120 Kg=351公噸 (年減少碳排放量)
28. 28 2.1 2.1 2.2 2.1 2.1 2.1 2 2.2 2.1 2 2.1 2.2 2.1 2 2.1 2.2 2.1 2.1 2.1 2.1 2 2.1 2.1 2.1 2 2.1 2.1 2 2.1 22222 1.9 2 1.9 2 1.9 22 1.9 2 1.9 2222 2.1 22 2.1 2 2.1 2.1 2 2.1 2.1 2 2.1 2 2.1 22222 1.9 2 1.9 1.9 222 2.1 2.1 2.2 2.1 2.1 2.1 2 2.2 2.1 2 2.1 2.2 2.1 2 2.1 2.2 2.1 2.1 2.1 2.1 2 2.1 2.1 2.1 2 2.1 2.1 2.1 2.2 2.1 2.1 2.1 2 2.2 2.1 2 2.1 2.2 2.1 2 2.1 2.2 2.1 2.1 2.1 2.1 2 2.1 2.1 2.1 2 2.1 1.8 1.8 1.8 1.8 1.8 1.8 1.7 1.8 1.8 1.7 1.7 1.8 1.7 1.7 1.7 1.7 1.7 1.8 1.7 1.7 1.7 1.8 1.7 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.7 1.8 1.8 1.8 1.7 1.8 1.7 1.8 1.7 1.8 1.7 1.7 1.8 1.7 1.7 1.8 1.6 1.7 1.7 1.7 1.7 1.6 1.7 1.6 1.7 1.6 1.7 1.7 1.6 1.6 1.6 1.6 1.6 1.5 1.6 1.6 1.6 1.6 1.6 1.7 1.6 1.8 1.7 1.8 1.8 1.8 1.8 1.9 1.8 1.9 1.8 1.9 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.7 1.7 1.7 1.8 1.7 1.6 1.7 1.7 1.6 1.6 1.7 1.6 1.7 1.6 1.7 1.6 1.7 1.7 1.7 1.8 1.7 1.7 1.8 1.8 1.8 1.8 1.8 1.7 1.7 1.7 1.7 1.8 1.8 0 0.5 1 1.5 2 2.5 1 4 7 10 13 16 19 22 25 28 31 34 37 40 43 46 49 52 55 58 61 64 67 70 73 76 79 82 85 88 91 94 97 100 103 106 109 112 115 118 121 124 每分鐘天然氣耗量 前基線 後基線
29. 29 節能設備費用說明:節能分享 公司原本鍋爐單月瓦斯費用1000元 安裝節能設備後，節能率12% 公司鍋爐單月瓦斯費用降為880元 節省金額120元 節省金額120元 節省金 額24元 節省金 額96元 公司保留做為公司營運金 節能分享金 公司無需另外提撥費用來支付瓦斯節能設備
