Garbling Techniques

Tutorial at Summer School on Secure and Oblivious Computation and Outsourcing
Notre Dame University, 9 May 2016

Transcript

1. Garbling Techniques David Evans www.cs.virginia.edu/evans Summer School on Secure Computation University of Notre Dame 9 May 2016
2. Collaborators Samee Zahur (UVA) Mike Rosulek (Oregon State)
3. Recap: Garbled Table Inputs Output x a b a1 b0 Ea1 ,b0 (x0 ) a0 b1 Ea0 ,b1 (x0 ) a1 b1 Ea1 ,b1 (x1 ) a0 b0 Ea0 ,b0 (x0 ) a0 or a1 x AND b0 or b1
4. This Lecture Inputs Output x a b a1 b0 Ea1 ,b0 (x0 ) a0 b1 Ea0 ,b1 (x0 ) a1 b1 Ea1 ,b1 (x1 ) a0 b0 Ea0 ,b0 (x0 ) 2 ciphertexts (AND) 0 ciphertexts (XOR) What to use for E Open Research Questions
5. Formalizing Garbling (CCS 2012) Garbling is a fundamental primitive
6. Garble Encode Evaluate Decode f garbled circuit F encoding info e garbled input X garbled output Y z decoding info d x
7. Garble Encode Evaluate Decode f garbled circuit F e X Y z d x Correctness property:
8. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Security properties:
9. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Security properties Privacy: F, X, and d leak reveals nothing beyond f(x) Obliviousness: F, X reveals nothing (new) Authenticity: given F, X, hard to find Y’ such that: Decode(Y’, d) ∉ { f(x), error }
10. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Cost of Garbling Storage and Bandwidth: large functions: dominated by size of F small functions: encode also matters Computation: Garble, Evaluate Encode, Decode
11. Yao’s Garbling Scheme? FOCS 1982 FOCS 1986
12. Yao’s Garbling Scheme? FOCS 1982 FOCS 1986 Neither paper (or any other by Yao) actually describes Yao’s Garbled Circuits
13. Inputs Output x a b a1 b0 Ea1 ,b0 (x0 ) a0 b1 Ea0 ,b1 (x0 ) a1 b1 Ea1 ,b1 (x1 ) a0 b0 Ea0 ,b0 (x0 ) Simple Garbling
14. Ea1 ,b0 (x0 ) Ea0 ,b1 (x0 ) Ea1 ,b1 (x1 ) Ea0 ,b0 (x0 ) Simple Garbling
15. Ea1 ,b0 (x0 ) Ea0 ,b1 (x0 ) Ea1 ,b1 (x1 ) Ea0 ,b0 (x0 ) Simple Garbling Try all four, can tell valid encryption output
16. Ea1 ,b0 (x0 ) Ea0 ,b1 (x0 ) Ea1 ,b1 (x1 ) Ea0 ,b0 (x0 ) Single Hash Garbling
17. Ea1 ,b0 (x0 ) Ea0 ,b1 (x0 ) Ea1 ,b1 (x1 ) Ea0 ,b0 (x0 ) Single Hash Garbling How can the evaluator know which row to decrypt?
18. Point-and-Permute Enca0,,b0, (c0 ) Enca0,,b1 (c0 ) Enca0,,b0 (c0 ) Enca1,b1 (c1 ) Beaver, Micali and Rogaway [STOC 1990] Select random bit for each wire: rw Set last bit of w0 to rw , w1 to ¬ra ra = 0, rb = 0
19. Point-and-Permute Enca1,,b1, (c1 ) Enca1,,b0 (c0 ) Enca0,,b1 (c0 ) Enca0,b0 (c0 ) Beaver, Micali and Rogaway [STOC 1990] Select random bit for each wire: rw Set last bit of w0 to rw , w1 to ¬ra Order table canonically: 00/01/10/11 ra = 1, rb = 1
20. Point-and-Permute Encoding garble table entries: Input wire labels (with selection bits) Output wire label Beaver, Micali and Rogaway [STOC 1990] Enca1,,b1, (c1 ) Enca1,,b0 (c0 ) Enca0,,b1 (c0 ) Enca0,b0 (c0 ) ra = 1, rb = 1
21. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x
22. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Bandwidth: 4 ciphertexts per gate Compute: 4 hashes per gate Compute: 1 hash per gate
23. Garbled Row Reduction Naor, Pinkas and Sumner [1999]
24. Garbled Row Reduction Naor, Pinkas and Sumner [1999]
25. Garbled Row Reduction Naor, Pinkas and Sumner [1999]
26. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Bandwidth: 4 ciphertexts per gate Compute: 4 hashes per gate Compute: 1 hash per gate Basic Scheme Garbled Row Reduction
27. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Bandwidth: 4 ciphertexts per gate Compute: 4 hashes per gate Compute: 1 hash per gate Basic Scheme Garbled Row Reduction Bandwidth: 3 ciphertexts per gate
28. Free-XOR Kolesnikov and Schneider [ICALP 2008] Global generator secret
29. Free-XOR Kolesnikov and Schneider [2008] Global generator secret
30. Free-XOR Kolesnikov and Schneider [2008] Global generator secret
31. Free-XOR Kolesnikov and Schneider [2008] Global generator secret XOR are free! No ciphertexts or encryption needed.
32. Security Assumptions for Free-XOR ICALP 2008 Proved secure in Random Oracle model Speculated that Correlation Robustness was sufficient TCC 2012 Correlation Robustness is not enough Proved secure with related-key and circularity assumption
33. Basic Point-and- Permute Garbled Row Reduction Free XOR Odd (AND) Generator Encryptions (H) 4 4 4 4 Evaluator Encryptions (H) 4 1 1 1 Ciphertexts Transmitted 4 4 3 3 Even (XOR) Generator Encryptions (H) 4 4 4 0 Evaluator Encryptions (H) 4 1 1 0 Ciphertexts Transmitted 4 4 3 0
34. Double Garbled Row Reduction (GRR2) Pinkas, Schneider, Smart, Williams 2009 EA0 ,B0 (C0 ) EA0 ,B1 (C1 ) EA1 ,B0 (C0 ) EA1 ,B1 (C0 ) Instead of learning output directly, need to do more work to find it
35. GRR2 Pinkas, Schneider, Smart, Williams 2009
36. Pinkas, Schneider, Smart, Williams 2009 GRR2
37. Pinkas, Schneider, Smart, Williams 2009 GRR2
38. Pinkas, Schneider, Smart, Williams 2009 GRR2 C0 = P(0) C1 = P(1)
39. Pinkas, Schneider, Smart, Williams 2009 GRR2 C0 = P(0) C1 = P(1) P(5) P(6) Garbled table:
40. Pinkas, Schneider, Smart, Williams 2009 GRR2 C0 = P(0) C1 = P(1) P(5) P(6) Garbled table: Incompatible with free-XOR
41. Basic Point-and- Permute GRR-1 Free XOR + GRR-1 + PnP GRR-2 Odd (AND) Generator Encryptions (H) 4 4 4 4 4+ Evaluator Encryptions (H) 4 1 1 1 1+ Ciphertexts Transmitted 4 4 3 3 2 Even (XOR) Generator Encryptions (H) 4 4 4 0 4+ Evaluator Encryptions (H) 4 1 1 0 1+ Ciphertexts Transmitted 4 4 3 0 2
42. FleXOR Kolesnikov, Mohassel, Rosulek 2014 S GRR-2 Gates Free-XOR Gates Single Ciphertext to Convert
43. Basic Free XOR + GRR-1 + PnP GRR-2 FleXOR Odd (AND) Generator Encryptions (H) 4 4 4+ 4+ Evaluator Encryptions (H) 4 1 1+ 1+ Ciphertexts Transmitted 4 3 2 2 Even (XOR) Generator Encryptions (H) 4 0 4+ {0, 1, 2} Evaluator Encryptions (H) 4 0 1+ {0, 1, 2} Ciphertexts Transmitted 4 0 2 {0, 1, 2}
44. Basic Free XOR + GRR-1 + PnP GRR-2 FleXOR Odd (AND) Generator Encryptions (H) 4 4 4+ 4+ Evaluator Encryptions (H) 4 1 1+ 1+ Ciphertexts Transmitted 4 3 2 2 Even (XOR) Generator Encryptions (H) 4 0 4+ {0, 1, 2} Evaluator Encryptions (H) 4 0 1+ {0, 1, 2} Ciphertexts Transmitted 4 0 2 {0, 1, 2} What cost should we be focusing on?
45. Cost of Garbling HA,B (C) SHA-256(A || B || gateID) ⊕ C ~2000/1000 ns (including network) Garbling/evaluating time per gate
46. Cost of Garbling HA,B (C) AES(kconst , K ) ⊕ K ⊕ C where K =2A⊕ 4B ⊕ gateID SHA-256(A || B || gateID) ⊕ C ~2000/1000 ns Bellare, Hoang, Keelveedhi, Rogaway 2013 “Fixed-key AES” using AES-NI ~ 15/7 ns Garbling/evaluating time per gate Actual computation cost: 12 cycles/byte ⇝ 200ns/50ns
47. Cost of Garbling HA,B (C) AES(kconst , K ) ⊕ K ⊕ C where K =2A⊕ 4B ⊕ gateID SHA-256(A || B || gateID) ⊕ C ~2000/1000 ns Bellare, Hoang, Keelveedhi, Rogaway 2013 “Fixed-key AES” using AES-NI ~ 15/7 ns Garbling/evaluating time per gate Time to transmit 80-bits at 1Gbps: 80ns Actual computation cost: 12 cycles/byte ⇝ 200ns/50ns
48. Basic Free XOR + GRR-1 + PnP GRR-2 FleXOR Odd (AND) Generator Encryptions (H) 4 4 4+ 4+ Evaluator Encryptions (H) 4 1 1+ 1+ Ciphertexts Transmitted 4 3 2 2 Even (XOR) Generator Encryptions (H) 4 0 4+ {0, 1, 2} Evaluator Encryptions (H) 4 0 1+ {0, 1, 2} Ciphertexts Transmitted 4 0 2 {0, 1, 2}
49. Half Gates Yan Huang, David Evans, and Jonathan Katz. Private Set Intersection: Are Garbled Circuits Better than Custom Protocols? [NDSS 2012]
50. Yan Huang, David Evans, and Jonathan Katz. Private Set Intersection: Are Garbled Circuits Better than Custom Protocols? [NDSS 2012]
51. Yan Huang, David Evans, and Jonathan Katz. Private Set Intersection: Are Garbled Circuits Better than Custom Protocols? [NDSS 2012] Journal of the ACM, January 1968 swap gates, configured (by generator) to do random permutation
52. Generator Half Gate Known to generator (but secret to evaluator)
53. Generator Half Gate Known to generator (but secret to evaluator)
54. Generator Half Gate Known to generator (but secret to evaluator)
55. Swapper: “Generator Half Gate” Known to generator (but secret to evaluator) With Garbled Row Reduction: Only need to send one ciphertext!
56. Evaluator Half-Gate Known (semantic value) to evaluator (but secret to generator)
57. Evaluator Half-Gate Known (semantic value) to evaluator (but secret to generator)
58. Generator Half-Gates Generator knows a Evaluator Half-Gates Evaluator knows b Implementing But, we need a gate where both inputs are secret…
59. Half + Half = Full Secret Gate random bit selected by generator “leaked” unknown known unknown
60. Half + Half = Full Secret Gate random bit selected by generator “leaked” unknown known unknown
61. Half + Half = Full Secret Gate random bit selected by generator “leaked” unknown known unknown
62. Half + Half = Full Secret Gate random bit selected by generator generator half gate evaluator half gate “leaked” unknown known unknown 2 ciphertexts total!
63. How to leak r ⊕ b? random bit selected by generator generator half gate evaluator half gate “leaked” unknown known unknown 2 ciphertexts total! Use r as point-and-permute bit for B (false) Evaluator has r ⊕ b on obtained wire!
64. Basic Free XOR + GRR-1 + PnP FleXOR Half- Gates Odd (AND) Generator Encryptions (H) 4 4 4+ 4 Evaluator Encryptions (H) 4 1 1+ 2 Ciphertexts Transmitted 4 3 2 2 Even (XOR) Generator Encryptions (H) 4 0 {0, 1, 2} 0 Evaluator Encryptions (H) 4 0 {0, 1, 2} 0 Ciphertexts Transmitted 4 0 {0, 1, 2} 0
65. Edit distance: Levenstein distance between two 200-byte strings AES: 1 block of encryption and key expansion, iterated 10 times Set intersection: 1024, 32-bit integers, iterated 10 times Zahur, Rosulek, and Evans [EuroCrypt 2015]
66. Free-XOR+GRR+PnP Half Gates Generator Encryptions (H) 4 4 Evaluator Encryptions (H) 1 2 Ciphertexts Transmitted 3 2 XORs Free ✓ ✓ Bandwidth ê33% Execution Time (edit distance) ê25% Energy ê21%
67. Can we do better?
68. Optimality of Two Ciphertexts Theorem (proof in ZER15 paper): Garbling a single AND gate requires 2 ciphertexts if garbling scheme is “linear”. “linear” operations: xor, polynomial interpolation
69. How to Do Better? • Non-linear operations • Gates that are not binary – chunk-ing circuit • Boolean logic • Reusable ciphertexts • Different security assumptions • …
70. Garble Encode Evaluate Decode f garbled circuit F e X Y f(x) d x Security properties Privacy: F, X, and d leak reveals nothing beyond f(x) Obliviousness: F, X reveals nothing (new) Authenticity: given F, X, hard to find Y’ such that: Decode(Y’, d) ∉ { f(x), error }
71. David Evans evans@virginia.edu www.cs.virginia.edu/evans OblivC.org mightBeEvil.org Credits: Mike Rosulek, Samee Zahur
