Hardening your Android app - Devoxx March2013

Talk for Android developers about improving their app security using built in platform features and 3rd party libraries. This session won’t just talk about the issues it will arm you with practical solutions and sample code to harden your app. I’ll also cover off some quick wins suitable of all levels of programmer.

#Encryption and key management on Android
#Using SSL better
#Android Permissions made easy
#Make it harder to pirate/repackage your app
#Commercial tools

Transcript

1. Hardening your Android App Scott Alexander-Bown Head of Android Mubaloo @scottyab
2. me: Scott Alexander-Bown •  Head of Android at Mubaloo •  Passionate about Android and mobile security •  Co-run SWmobile meetup group •  Follow me @scottyab Favourite apps
3. It's not about... Fear!
4. It's not about... 100%
5. Agenda •  Why? o  Attacker motivations o  Reverse engineering •  Hardening techniques o  Android Permissions o  Encryption and key management on Android o  Using SSL better o  Make it harder to pirate/repackage your app o  Device Administration policies o  Miscellaneous tips
6. •  Different ads •  Different market •  Extract assets or API keys •  Insert malware •  Software piracy •  Malware and security research •  Fun! Motivations for hacking an app
7. Reverse engineering Android app
8. Apktool •  http://bit.ly/apktool •  Apktool o  apktool d myapp.apk o  apktool b myapp newmyapp.apk
9. Santoku Linux •  Linux ISO •  Pre-installed platform SDKs, drivers, and utilities •  Decompilation and disassembly tools •  Scripts to detect common issues in mobile applications •  Scripts to automate decrypting binaries, deploying apps, enumerating app details, and more •  https://santoku-linux.com/
10. *Disclaimer: I work for Via Forensics as of Monday
11. Techniques for hardening
12. Protecting internal storage Creating world-readable files is very dangerous •  Do o  File creation mode: Context.MODE_PRIVATE •  Don't use o  MODE_WORLD_READABLE o  MODE_WORLD_WRITEABLE o  (deprecated in API level 17)
13. Permissions •  Are all the permissions required? Instead of •  Permission types (protection level) o  Normal o  Dangerous o  Signature
14. Custom Permission example • Declared custom permission • Another app/component using the permission
15. Don't leak permissions •  Protect entry points (receivers, services, content providers) •  Exported=false •  Context.checkCallingPermission("android.permission. CAMERA") •  Context.enforceCallingPerrmissions(...) •  Tip: Local broadcast manager for in app notifications
16. Encryption: 3rd party libs •  SQL Cipher o  256-bit AES Encrypt SQLite database o  http://sqlcipher.net/sqlcipher-for-android •  Keyczar - Open source cryptographic toolkit o  http://www.keyczar.org o  https://github.com/kruton/android-keyczar-demo •  IO Chiper - virtual encrypted disk o  Clone of java.io o  https://guardianproject.info/code/iocipher
17. Encryption: Key management Two 'ideal world' solutions •  Don't store the key on the device •  Use a system service (such as keychain) •  Tip: Minimise keys time in ram (null after using them)
18. Encryption: Generate random key •  Note: New Implementation of SecureRandom in Android 4.2
19. • Use a key derivation algorithm: PBK2F2 • (secure)random salt and iteration count • Tip: Ensure derivation method takes more than 100ms • Code for what to do and what not to do: https://github.com/ nelenkov/android-pbe Password based encryption (PBE)
20. Password based encryption (PBE)
21. Encryption: no no's •  Store encryption keys in app •  Log/debug statements with encryption keys •  Rely on OS encryption •  Write your own encryption algorithms
22. SSL •  Use Https by default •  What about Man in the middle (MITM) attacks? o  Trusting all certificates o  Compromised CA
23. SSL Tips •  Pay attention to security exceptions •  Verify the certificate issuing hostname •  SSL Pinning (public key pinning) o Android pinning - https://github.com/moxie0/ AndroidPinning o Android 4.2 - X509TrustManagerExtensions
24. SSL: wipe the slate clean •  Don't use a CA! •  Server side o  create your own 4096bit signing certificate (keep offline) o  sign your certs for the web services •  Client/app o  include the signing cert (in a keystore) o  validate against it
25. Make your app harder to pirate •  Google License Verification Library o  Modify LVL source as much as possible o  com.android.vending.licensing.* o  Focus on core of the LVL logic: LicenseChecker and LicenseValidator. •  Offload license validation to a trusted server
26. Tamper resistance •  Checksum of the app code with validation check on server or unlocker app •  Reflection based tamper checks •  Check installer is from play store
27. Obfuscation: Proguard •  Proguard been around for 10+ years •  Project properties file, uncomment #proguard.config= •  Only applied when building release versions •  Entry points should be excluded -keep public class * extends android.app.Activity •  Most popular 3rd party libs/jars come with proguard config •  Bonus: ~50% reduction in .apk size
28. •  Optimize and obfuscate tuned for the Android platform/ Dalvik bytecode. •  Encrypt strings •  Encrypt entire classes •  Hide access to sensitive APIs •  Add tamper detection •  Thoroughly remove Android logging code •  More info: http://www.saikoa.com/ Obfuscation: Dexguard
29. Remove logging using Proguard
30. Device Management Policies •  Since Android 2.2 •  Enforce o  Device lock o  Passcode type (pin, pattern) o  Password complexity o  Device encryption (3.0+) o  Device wipe •  New policies are added in each release •  Policies set by different apps can only change policies to make them stronger •  Cannot uninstall an app while the device admin is still active
31. Device Management Policies •  Define a policy as an xml resource •  Reference in manifest •  Create a Device Administration broadcast receiver •  Implement a Device Policy Controller o  DevicePolicyManager.isAdminActive?
32. Misc tips Validation •  User input - SQL Injection Anti tamper •  Detect rooted device •  Detect emulator •  isDebuggable? Web views •  Disable Javascript •  Use https •  Validate URLS •  Restrict JavaScript interface
33. Misc tips Avoid unsecured components •  Don't use SMS for sensitive data •  Don't use SD card •  Avoid sensitive data in public intents •  Avoid sensitive data in sticky broadcasts •  allowBackups=“false” GUID (Privacy concern) •  Generate a large unique number •  Don't use phone number or IMEI
34. Misc tips: development practices Infrastructure •  Code •  Keystore and password •  App store user credentials o  Enable 2 step authentication o  Grant access rather than share account details Process •  Educate developers o  Don't ignore the lint warnings •  Audit / security code review
35. Summary •  Go hack your own apps •  Using https isn't enough pin your certs •  Encrypt app data •  Proguard your apps •  Android is getting more secure
36. Q&A @scottyab dev@scottyab.com
37. Bonus Slides Security features of Jelly Bean (Android 4.1 & 4.2)
38. Security enhancements in Jelly Bean *Data collected during a 14-day period ending on March 4, 2013
39. Security enhancements in Jelly Bean •  New implementation of SecureRandom •  Javascript Interface methods in WebViews must now be annotated (@JavascriptInterface) •  Application verification
40. Security enhancements in Jelly Bean •  Content Provider default access has changed •  Remote blacklisting CAs •  Secure USB debugging •  Hidden developer options
41. Ref/More info... Using Cryptography to Store Credentials Safely http://android-developers.blogspot.co.uk/2013/02/using-cryptography-to-store-credentials.html Security Enhancements in Jelly Bean http://android-developers.blogspot.co.uk/2013/02/security-enhancements-in-jelly-bean.html Security Tips https://developer.android.com/training/articles/security-tips.html 42 tips on app security https://viaforensics.com/resources/reports/best-practices-ios-android-secure-mobile- development/ Why Eve and Mallory Love Android: An Analysis of Android SSL (In)Security http://www2.dcsec.uni-hannover.de/files/android/p50-fahl.pdf @scottyab dev@scottyab.com
