Extending your apps to wearables

Learn how to take advantage from wearables? In this talk and learn how easily add support for Android Wear and Sony Smart Extension devices to your existing application. Besides that we'll talk about UI/UX on small screen, project structure best practices and finally decide what platform is more perspective and easier to work with from developer point of view.

Transcript

1. Extending your apps to
   wearables
   Vitalik Zasadnyy Ostap Andrusiv
   @zasadnyy @p1f
   IT Arena Lviv
   October 2-4


   View Slide

2. View Slide

3. View Slide

4. View Slide

5. View Slide

6. Custom OS Android Wear
   ?


   View Slide

7. Sony Smart Extensions
   Overview


   View Slide

8. “Sony made wearables before it was mainstream...”


   View Slide

9. Supported devices


   View Slide

10. How the Smart Extension apps work


    View Slide

11. Architecture


    View Slide

12. Smart Extension APIs


    View Slide

13. Compatibility


    View Slide

14. Development


    View Slide

15. Requirements
    ● Eclipse / Android Studio
    ● ADT
    ● Sony Add-on SDK
    ● Smart Connect
    ● Host Application


    View Slide

16. Project setup & structure
    ● Use sample apps
    Official library
    Un-official library
    Actually project


    View Slide

17. Hello IT Arena!
    ● System.out.print(“Hello IT Arena!”) ?
    ● AndroidManifest.xml ~ 40 lines, 10 intent filter actions
    1
    2
    4
    3


    View Slide

18. Security
    ”com.sonyericsson.extras.liveware
    .aef.EXTENSION_PERMISSION” />
    AndroidManifest.xml


    View Slide

19. Using API
    Intent intent = new Intent(CONTROL_VIBRATE_INTENT);
    intent.putExtra(EXTRA_ON_DURATION, onDuration);
    intent.putExtra(EXTRA_OFF_DURATION, offDuration);
    sendToHostApp(intent);
    ScreenControll.java


    View Slide

20. Bundle bundle1 = new Bundle(); bundle1.putInt(Control.
    Intents.EXTRA_LAYOUT_REFERENCE, R.id.exercise_name);
    bundle1.putString(Control.Intents.EXTRA_TEXT, name);
    Bundle bundle2 = new Bundle(); bundle2.putInt(Control.
    Intents.EXTRA_LAYOUT_REFERENCE, R.id.exercise_number);
    bundle2.putString(Control.Intents.EXTRA_TEXT, number);
    Bundle bundle3 = new Bundle(); bundle3.putInt(Control.
    Intents.EXTRA_LAYOUT_REFERENCE, R.id.exercise_timer);
    bundle3.putString(Control.Intents.EXTRA_TEXT, UiUtils.
    formatTimeLeft(timeLeft));
    Bundle[] bundleData = new Bundle[5];
    bundleData[0] = bundle1;
    bundleData[1] = bundle2;
    bundleData[2] = bundle3;
    showLayout(R.layout.exercise_screen, bundleData);
    Using API - HELL


    View Slide

21. Debugging
    1. Connect phone
    2. Run
    3. Debug
    Nothing special!


    View Slide

22. Testing


    View Slide

23. Emulator


    View Slide

24. UI Guidelines


    View Slide

25. No UI Guidelines!


    View Slide

26. Things to consider
    ● Resolution: 128x128 or 220x176
    ● Information levels
    ● Dimmed mode design
    ● Icon sizes, buttons …


    View Slide

27. Publishing


    View Slide

28. Publishing
    1. Package as plain Android app
    2. Upload to store
    3. Add to description:
    “Smart Connect extension for SmartWatch 2”


    View Slide

29. Android Wear SDK
    Overview


    View Slide

30. Supported devices


    View Slide

31. Zero Interaction
    Vision
    Automatic Fast
    Assistant


    View Slide

32. Context Stream


    View Slide

33. One Action, Big Gestures, Fast Interaction
    Design Principles


    View Slide

34. Development


    View Slide

35. Architecture
    Data Layer API in Play Services
    Bluetooth


    View Slide

36. Wear Apps
    Android 4.4W Bluetooth
    Outer World
    somehow
    Awesome App
    Intents
    Play Store
    .apk
    wearable .apk
    Android Wear
    Play Services
    Data API
    Node API
    Message API
    wearable.apk


    View Slide

37. Notifications
    work out of the box


    View Slide

38. Notifications: Wearable Features
    Voice Input Stacking
    Pages


    View Slide

39. Full-Screen Activities
    Wearable UI Library:
    ● CircledImageView
    ● WearableListView
    ● CardFragment
    ● ConfirmationActivity
    ● GridViewPager
    ● WatchViewStub


    View Slide

40. Debugging
    ● Direct connect
    ○ use micro-usb cable and connect the device
    ● Via Bluetooth
    ○ enable debugging on phone & wearable
    ○ enable Bluetooth debugging on wearable
    ○ adb forward tcp:4444 localabstract:/adb-hub;
    adb connect localhost:4444


    View Slide

41. Emulator


    View Slide

42. UI Guidelines


    View Slide

43. Remember Wear
    Design Principles:
    ● One Action
    ● Big Gestures
    ● Fast Interaction


    View Slide

44. Publishing


    View Slide

45. App APK
    Wearable APK


    View Slide

46. Packaging
    dependencies {
    compile fileTree(dir: 'libs', include: ['*.jar'])
    compile 'com.google.android.gms:play-services:5.0.+@aar'
    compile 'com.android.support:support-v4:20.0.+''
    wearApp project(':wear')
    }
    build.gradle


    View Slide

47. Put it all together
    or “we need more wearable integrations...”


    View Slide

48. Business case
    ?


    View Slide

49. Architecture
    View
    Presenter
    Model
    IView, Activity, ScreenControl
    Common


    View Slide

50. Project structure
    include ':smartExtensionAPI'
    include ':smartExtensionUtils'
    include ':visionTrainingLib'
    include ':visionTrainingWear'
    include ':visionTraining'
    settings.gradle


    View Slide

51. Project structure


    View Slide

52. Gradle config
    dependencies {
    compile project(':smartExtensionUtils')
    compile project(':visionTrainingLib')
    wearApp project(':visionTrainingWear')
    }
    build.gradle


    View Slide

53. Eyes Exercises
    bit.ly/eyes-exercises


    View Slide

54. The biggest Google related event in Ukraine


    View Slide

55. Thanks for attention!
    Questions?
    Vitalik Zasadnyy Ostap Andrusiv
    @zasadnyy @p1f


    View Slide
